8. Help
65
For Fax Advantage assistance, call 1-800-435-7329.
4. Remove the jammed paper (1) from the
fuser unit by pulling it upwards carefully,
then install the drum and toner unit.
5. Push back the levers (1) to the original
position.
3 Close the front cover (1) by pushing down
on both sides, until locked.
4 Re-insert the recording paper (1).
L Before re-inserting, make sure to fan and
straighten the recording paper.
5 Attach the paper tray cover (1), then push
back the tension plate (2).
1
1
1
1
2
1
FL611-PFQX2072ZA-en.book Page 65 Thursday, December 21, 2006 11:10 AM
