3 Insert the lower tabs of the adaptor into
the unit’s bottom slots (A), then insert by
pushing down the levers of the adaptor
into the upper slots (B).
R The words “UP WALL” should be
facing up.
A
A
B
B
4 Mount the unit on a wall then slide down
to secure in place.
R This product is compliant with the
following wall phone plate sizes (2
types).
1
83 mm (3
1
/4 inches)
2
102 mm (4 inches)
Fit the slots of the unit onto the
corresponding wall phone plate tabs
for (
3
) and (
4
) respectively.
3
4
3
4
1
2
Charger
Drive the screws (
1
) (not supplied) into the
wall.
2
27.2 mm (1
1
/16 inches)
1
2
For assistance, please visit http://shop.panasonic.com/support
85
Useful Information
