Page 5
E64C-002E
WARNING
Beware of guide for feeder cart.
You may potentially stumble over the guide for feeder cart and get injured when operating
without the feeder cart.
We recommend that you should paste yellow and black tapes for danger indication onto the floor where is
120 mm or more away from around the machine, in order to draw a distinct line between the operator area
and the maintenance area (see Fig.2).
We recommend that you should keep away from the most protrudent part (guide for feeder cart) of the
machine by 120 mm or more (outside of the area with yellow and black stripes), as indicated by Fig.2.
Guide for feeder cart
Fig.1
Color
Yellow
Black
Fig.2 (Top view)
M108
E64C-E-XXA00-A03-00
E64C-001E
1
2
