WARNING
Do not peer into the board eject area.
Ejected boards can strike and injure eyes.
In case you use the machine on a standalone basis, be careful of the receipt of unloaded boards. Normally
we cannot look inside the opening for unloading because the machine is installed close to the next machine
in whole line. If, however, you use it on a standalone basis, it is possible. We recommend you to add a buffer
stocker to the unloading side.
Board flow direction
Do not look inside.
Machine’s side view
