1-1 Package
Before using this product, be sure to check the packed objects as shown below.
Touch panel console
LP-ADP50
□
Instructions before
using product
□
General Information
for Safety,
Compliance, and
Instructions
1 unit qty.: 1 qty.: 1
ンㄆㄇㄆㄓㄆㄏㄆ
• For details on how to operate the laser marker/laser welding machine using the touch panel console, refer to the manual
for the laser marker/laser welding machine.
1-2 Specification
This product is a color liquid crystal display with a touch panel dedicated to our laser marker/laser welding machine.
This product is developed/manufactured for use in an industrial environment.
Item Specification of LP-ADP50
Power voltage DC24V±10% (supplied from laser marker/laser welding machine)
Consumption current 300mA or less
Display device
Color liquid crystal display with touch panel
10.1 inch TFT WXGA
Resolution 1280 × 3 × 800 (pixel)
Viewing angle Omnidirectional: -85° to 85° (Typ.)
Backlight LED
Operating ambient temperature *1 0 to +50°C
For storage: -10 to +70°C
Operating ambient humidity *1 10 to 90%RH
For storage: 10 to 90%RH
Protection degree IP54 (excluding the cable connector)
Material Case: PC + ABS
Cable: PVC
Weight Approx. 1.5kg
Applicable laser marker/laser
welding machine
LP-RH series
LP-ZV series
LP-M series/LP-S series/LP-Z series
LP-400 series/LP-V series
VL-W1 series
*1 : No condensation or freezing shall be allowed. If there is a gap between the stored temperature and operating
temperature, make sure to have the product get used to the operating ambient temperature gradually prior to use to
prevent the dew condensation.
