1-3 Name of Each Component and function
r
e
q
w
1. Hook hole for wall hanging
This is a hook hole used when hanging this product on a wall.
2. Fixing screw hole (8 holes)
It is used when fixing this product.
You can use either inside 4 holes or outside 4 holes.
3. Connection cable
A cable that connects to the controller of the laser marker/laser welding machine.
ンㄆㄇㄆㄓㄆㄏㄆ
• For the connection, refer to the manual for laser marker/laser welding machine.
4. Display
Touch panel display.
• Do not press the surface of the touch panel with a sharp-pointed object or a pencil.
