13
DVQP1242
Before Use
Before use
Camera handling
Keep the camera away from excessive vibration, force, or pressure.
Avoid using the camera under the following conditions, which may damage the lens,
monitor, viewfinder, or camera body.
This may also cause the camera to malfunction or prevent recording.
Dropping or hitting the camera against a hard surface
Pushing with excessive force on the lens or monitor
Do not hold the lens barrel as you take pictures. There is a risk that your finger will
be trapped as the lens retracts.
There are times when rattling sounds or vibrations will come from the camera, but
these are due to the motion of the aperture, the zoom and the motor and do not
indicate a defect.
The camera is not dust resistant, splash resistant, or waterproof.
Avoid using the camera in places with excessive dust or sand, or where water can
come into contact with the camera.
Avoid using the camera under the following conditions, which present a risk that sand,
water, or foreign material may enter the camera through the lens or openings around
buttons. Be especially careful because these conditions may damage the camera, and
such damage may not be repairable.
In extremely dusty or sandy places
In the rain or by the shore, where the camera may be exposed to water
Condensation (When the lens, the monitor, or viewfinder, is fogged up)
Condensation may occur when the camera is exposed to sudden changes of
temperature or humidity. Avoid these conditions, which may make the lens, monitor, or
viewfinder dirty, cause mould, or damage the camera.
If condensation does occur, turn off the camera and wait about two hours before using
it. Once the camera adjusts to the surrounding temperature, the fogging will clear
naturally.

Table of Contents

Other manuals for Panasonic LUMIX DC-FZ80

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DC-FZ80 and is the answer not in the manual?

Panasonic LUMIX DC-FZ80 Specifications

General IconGeneral
Megapixel18.9 MP
Camera typeBridge camera
Sensor typeMOS
Image stabilizerYes
Image sensor size1/2.3 \
Image formats supportedJPEG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4896 x 3672 pixels
Still image resolution(s)4896 x 3672
BluetoothNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesNight
Photo effects-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Shutter priority
Self-timer delay2, 10 s
Digital zoom4 x
Optical zoom60 x
Number of aspheric elements6
Lens structure (elements/groups)14/12
Maximum focal length (35mm film equiv)215 mm
Normal focusing range (tele)- m
Product colorBlack
Light meteringCentre-weighted, Spot
ISO sensitivity80, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Power source typeBattery
Battery voltage7.2 V
Battery capacity895 mAh
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1.5 - 6.1 m
Flash range (wide)0.3 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC
Resolution at capture speed640x480@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution (numeric)1040000 pixels
Viewfinder typeElectronic
USB version2.0
USB connectorMicro-USB B
HDMI connector typeMicro
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth119.2 mm
Width130.2 mm
Height94.3 mm
Weight616 g
