Panasonic LUMIX DC-FZ80 Operating Instructions For Advanced Features

283
DVQP1242
Others
Optional accessories
External Flash (optional)
After attaching the flash (DMW-FL200L, DMW-FL360L, DMW-FL580L: optional), the
effective range will be increased when compared to the camera’s built-in flash.
Preparation
Close the built-in flash and set the camera [ON/OFF] switch to [OFF].
1
Attach the external flash to the hot shoe and then turn on the camera and the
external flash
• Refer to (→143) for changing the settings for external flashes on the camera.
• Refer to (→148) about the settings for the wireless flash.
When using other commercially available external flashes that don’t
offer direct communication with the camera (DC-FZ80)
• It is necessary to set the exposure on the external flash when it is used. When you use
an external flash in Auto Mode, use an external flash that allows you to set the aperture
value and ISO sensitivity to match the same settings on the camera.
• Set the camera to Aperture-Priority AE Mode or Manual Exposure Mode and then set
the same aperture value and ISO sensitivity on the external flash. (The proper exposure
cannot be achieved because the aperture value changes in Shutter-Priority AE Mode.
The light of the external flash cannot be properly adjusted since the aperture value
cannot be fixed in Programme AE Mode.)
●
You can set the aperture value, shutter speed and ISO sensitivity on the camera even when the
external flash is attached.
●
Some commercially available external flashes have synchro terminals with high-voltage or
reversed polarity. If such flashes are used, they could cause a malfunction or hinder normal
operation of the camera.
●
Be sure to hold both the camera and the external flash when it is attached to the camera. If you
hold only the external flash, it could become detached from the camera.
●
If you take pictures close to the subject while taking wide-angle pictures, the light of the flash is
obstructed by the lens and the bottom of the screen may be dark.
●
Refer to the operating instructions of the external flash for further details.

Panasonic LUMIX DC-FZ80 Specifications

General

Megapixel	18.9 MP
Camera type	Bridge camera
Sensor type	MOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPEG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4896 x 3672 pixels
Still image resolution(s)	4896 x 3672
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Night
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Self-timer delay	2, 10 s
Digital zoom	4 x
Optical zoom	60 x
Number of aspheric elements	6
Lens structure (elements/groups)	14/12
Maximum focal length (35mm film equiv)	215 mm
Normal focusing range (tele)	- m
Product color	Black
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	895 mAh
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1.5 - 6.1 m
Flash range (wide)	0.3 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC
Resolution at capture speed	640x480@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Cables included	AC

Weight and Dimensions

Depth	119.2 mm
Width	130.2 mm
Height	94.3 mm
Weight	616 g
