Panasonic LUMIX DC-FZ80 Operating Instructions For Advanced Features

24
DVQP1242
Preparations
Charging battery
Notes on charging time
When using the AC adaptor (supplied)
Charging time Approx. 170 min.
• The charging time indicated above is the time required for charging in case when the
battery is completely used up. The time required for charging differs depending on
conditions of battery usage. Charging takes longer in cases when temperatures are
either high or low and when the battery has not been used for a long period of time.
• The time required for charging through the computer varies depending on the power
supply capacity of the computer.
●
Do not use any other USB connection cables except the supplied one. Doing so may cause
malfunction of the camera.
●
Do not use any other AC adaptors except the supplied one.
●
Do not use a USB extension cable.
●
The AC adaptor (supplied) and the USB connection cable (supplied) are dedicated accessories of
this camera. Do not use them for other devices.
●
Remove the battery after use. (The battery will be exhausted if left for a long period of time after
being charged.)
●
If there is any trouble related to the electrical outlet (i.e. power failure), charging may not complete
properly. Disconnect the USB connection cable (supplied) and reconnect it to the camera.
●
If the charging lamp does not light even when the camera is connected to the AC adaptor
(supplied) or a computer, check to make sure it is properly connected. (→22)
Remaining battery
50
p
Remaining battery (only when using battery)
(flashes red)
If the battery mark flashes red, recharge or replace a fully charged
battery.

Panasonic LUMIX DC-FZ80 Specifications

General

Megapixel	18.9 MP
Camera type	Bridge camera
Sensor type	MOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPEG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4896 x 3672 pixels
Still image resolution(s)	4896 x 3672
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Night
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Self-timer delay	2, 10 s
Digital zoom	4 x
Optical zoom	60 x
Number of aspheric elements	6
Lens structure (elements/groups)	14/12
Maximum focal length (35mm film equiv)	215 mm
Normal focusing range (tele)	- m
Product color	Black
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	895 mAh
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1.5 - 6.1 m
Flash range (wide)	0.3 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC
Resolution at capture speed	640x480@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Cables included	AC

Weight and Dimensions

Depth	119.2 mm
Width	130.2 mm
Height	94.3 mm
Weight	616 g
