265
DVQP1242
Wi-Fi
About connections
Editing items registered in Favourite
[Setup] → [Wi-Fi] → [Wi-Fi Function]
→ [Select a destination from Favorite]
1
Select the Favourite item you wish to edit and press
[Remove from Favorite]
[Change the Order in Favorite] Select the destination.
[Change the Registered Name]
For details on how to enter characters, refer to “Entering
Text” (→50)
Up to 30 characters can be entered. A double-byte character
will be treated as two characters.
Registering and saving frequently used Wi-Fi connection settings to
Favourites (→264)
The number of settings that can be saved in the history is limited.
Checking connection details of History or Favourite
When selecting History or Favourite items, you can view connection details by pressing the [DISP.]
button.
Performing [Reset Wi-Fi Settings] deletes content registered in History and Favourite.
If the device you want to connect to (smartphone, etc.) is connected to a wireless access point
other than the camera, you cannot connect the device to the camera using [Direct]. Change the
Wi-Fi settings of the device you want to connect to so that the access point to be used is set to the
camera.
You can also select [New Connection] and reconnect the devices. (→233, 243)
When using [Select a destination from History] or [Select a destination from Favorite] to connect to
a network to which many PCs are connected, it may be difficult to make the connection because
the camera searches for previously connected equipment out of a large number of equipment
pieces. If you cannot connect, retry the connection using [New Connection].

Table of Contents

Other manuals for Panasonic LUMIX DC-FZ80

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DC-FZ80 and is the answer not in the manual?

Panasonic LUMIX DC-FZ80 Specifications

General IconGeneral
Megapixel18.9 MP
Camera typeBridge camera
Sensor typeMOS
Image stabilizerYes
Image sensor size1/2.3 \
Image formats supportedJPEG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4896 x 3672 pixels
Still image resolution(s)4896 x 3672
BluetoothNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesNight
Photo effects-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Shutter priority
Self-timer delay2, 10 s
Digital zoom4 x
Optical zoom60 x
Number of aspheric elements6
Lens structure (elements/groups)14/12
Maximum focal length (35mm film equiv)215 mm
Normal focusing range (tele)- m
Product colorBlack
Light meteringCentre-weighted, Spot
ISO sensitivity80, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Power source typeBattery
Battery voltage7.2 V
Battery capacity895 mAh
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1.5 - 6.1 m
Flash range (wide)0.3 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC
Resolution at capture speed640x480@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution (numeric)1040000 pixels
Viewfinder typeElectronic
USB version2.0
USB connectorMicro-USB B
HDMI connector typeMicro
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth119.2 mm
Width130.2 mm
Height94.3 mm
Weight616 g
