298
DVQP1242
Others
Q&A Troubleshooting
Monitor/viewfinder
The monitor/viewfinder is turned off although the camera is turned on.
If no operations are performed during the set time period [Auto LVF/Monitor Off] (→205) is
activated, and the monitor/viewfinder turns off.
It may flicker for an instant or the brightness of the screen may change significantly for an
instant.
This occurs due to the aperture of the lens changing when the shutter button is pressed halfway, or
when the brightness of the subject changes. This is not a malfunction.
Cannot switch between the monitor and viewfinder when pressing [LVF] button.
When it is connected to a computer or printer, the camera can display pictures on the monitor only.
Playback
Cannot view pictures. There are no recorded pictures.
A card is not inserted in the camera.
Has the file name of the picture been changed on a computer? If so, it cannot be played back on
the camera.
It is recommended to use the “PHOTOfunSTUDIO” software (→273) to write pictures from PC
to card.
Set [Playback Mode] to [Normal Play]. (→211)
Red areas in pictures appear blackened.
When the digital red-eye correction ([
], [ ]) is operating, red areas may be blackened.
We recommend closing the built-in flash, setting the flash mode to [
], or turning [Red-Eye
Removal] to [OFF] before recording. (→183)

Table of Contents

Other manuals for Panasonic LUMIX DC-FZ80

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DC-FZ80 and is the answer not in the manual?

Panasonic LUMIX DC-FZ80 Specifications

General IconGeneral
Megapixel18.9 MP
Camera typeBridge camera
Sensor typeMOS
Image stabilizerYes
Image sensor size1/2.3 \
Image formats supportedJPEG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4896 x 3672 pixels
Still image resolution(s)4896 x 3672
BluetoothNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesNight
Photo effects-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Shutter priority
Self-timer delay2, 10 s
Digital zoom4 x
Optical zoom60 x
Number of aspheric elements6
Lens structure (elements/groups)14/12
Maximum focal length (35mm film equiv)215 mm
Normal focusing range (tele)- m
Product colorBlack
Light meteringCentre-weighted, Spot
ISO sensitivity80, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Power source typeBattery
Battery voltage7.2 V
Battery capacity895 mAh
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1.5 - 6.1 m
Flash range (wide)0.3 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC
Resolution at capture speed640x480@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution (numeric)1040000 pixels
Viewfinder typeElectronic
USB version2.0
USB connectorMicro-USB B
HDMI connector typeMicro
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth119.2 mm
Width130.2 mm
Height94.3 mm
Weight616 g
