306
DVQP1242
Others
Usage cautions and notes
AC adaptor (supplied)
Keep at least 1 m (3.3 feet) away from AM radio (may cause radio interference).
The AC adaptor (supplied) may generate whirring sounds when it is being used. This is
not a malfunction.
After use, be sure to disconnect the power supply device from the electrical outlet. (A
very small amount of current is consumed if it is left connected.)
Memory cards
To prevent damage to cards and data
Avoid high temperatures, direct sunlight, electromagnetic waves, and static electricity.
Do not bend, drop, or expose to strong impacts.
Put the card in the card case or the storage bag after use and when storing or
carrying the card.
Do not touch terminals on reverse of card or allow them to become dirty or wet.
Recorded data may be damaged or lost if the camera breaks down due to inappropriate
handling. Panasonic will not be liable for any damage caused due to loss of recorded
data.
When disposing of/transferring memory cards
If using the “format” or “delete” functions on your camera or computer, this only
changes the file management information, and does not completely delete the data
from within the memory card. When disposing of or transferring your memory cards,
we recommend physically destroying them, or using commercially available computer
data erasing software to completely delete the data from the card. Data within
memory cards should be managed responsibly.
When using a tripod or unipod
Do not apply excessive force or tighten screws when they are crooked. (This may
damage the camera, screw hole, or label.)
Ensure that the tripod is stable. (Refer to the tripod instructions.)
You may not be able to remove the card or the battery when using a tripod or unipod.

Table of Contents

Other manuals for Panasonic LUMIX DC-FZ80

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DC-FZ80 and is the answer not in the manual?

Panasonic LUMIX DC-FZ80 Specifications

General IconGeneral
Megapixel18.9 MP
Camera typeBridge camera
Sensor typeMOS
Image stabilizerYes
Image sensor size1/2.3 \
Image formats supportedJPEG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4896 x 3672 pixels
Still image resolution(s)4896 x 3672
BluetoothNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesNight
Photo effects-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Shutter priority
Self-timer delay2, 10 s
Digital zoom4 x
Optical zoom60 x
Number of aspheric elements6
Lens structure (elements/groups)14/12
Maximum focal length (35mm film equiv)215 mm
Normal focusing range (tele)- m
Product colorBlack
Light meteringCentre-weighted, Spot
ISO sensitivity80, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Power source typeBattery
Battery voltage7.2 V
Battery capacity895 mAh
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1.5 - 6.1 m
Flash range (wide)0.3 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC
Resolution at capture speed640x480@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution (numeric)1040000 pixels
Viewfinder typeElectronic
USB version2.0
USB connectorMicro-USB B
HDMI connector typeMicro
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth119.2 mm
Width130.2 mm
Height94.3 mm
Weight616 g
