Panasonic lumix DC-TZ90 User Manual

22
DVQP1288
Preparations
Charging battery
Charging the battery
We recommend charging in a location where the ambient temperature is between 10 °C
and 30 °C (50 °F to 86 °F) (same for the battery temperature).
Insert the battery into the camera.
Make sure that the camera is turned off.
The battery can be charged from an outlet or through a PC.
USB connection cable (supplied)
AC adaptor (supplied)
To the electrical outlet
Computer
Getting ready: Turn on the computer.
When charging the camera, connect the USB connection cable (supplied) to the
[USB/CHARGE] socket.
[USB/CHARGE] socket
• This terminal is located at the bottom when the camera is in
an upright position.
• Always check the direction of the socket, and hold the plug
straight to insert or remove it. (If the cable is inserted in the
wrong direction, the socket could become deformed and cause
faulty operation.)
Also, do not insert into the wrong socket. Doing so may cause
damage to this unit.

Panasonic lumix DC-TZ90 Specifications

General

Sensor	1/2.3-inch High Sensitivity MOS Sensor
Effective Pixels	20.3 Megapixels
Lens	LEICA DC VARIO-ELMAR
Dimensions	112.0 x 67.3 x 41.2 mm
Focal Length	4.3 - 129mm (24 - 720mm in 35mm equivalent)
Aperture	F3.3 - F6.4
ISO Sensitivity	80-3200 (expandable to 6400)
Display	3.0-inch TFT Screen LCD Display (1040K dots)
Viewfinder	0.2-inch EVF (1166K dots)
Video Recording	4K UHD (3840x2160) at 30p/25p
Connectivity	Wi-Fi
Battery Life	Approx. 380 shots (CIPA standard)
Weight	Approx. 322g with Battery and SD Memory Card
Storage Media	SD/SDHC/SDXC memory card
Image Stabilization	5-axis Hybrid O.I.S. (Optical Image Stabilizer)
