Panasonic Lumix DMC-FS16 User Manual

- 103 -
Connecting to other equipment
Printing the Pictures
If you connect the camera to a printer supporting PictBridge, you can select the pictures to
be printed out and instruct that printing be started on the camera’s LCD monitor.
• Some printers can print directly from the card removed from the camera. For details, refer to
the operating instructions of your printer.
Preparations:
Turn on the camera and the printer.
Remove the card before printing the pictures from the built-in memory.
Check print quality and other settings on the printer before printing the pictures.
A USB connection cable (supplied)
• Check the directions of the connectors, and plug them straight in or unplug them straight out.
(Otherwise the connectors may be bent out of shape which will cause a malfunction.)
B Align the marks, and insert.
• Use a battery with sufficient battery power or the AC adaptor (optional) and DC coupler
(optional). If the remaining battery power becomes low while the camera and the printer are
connected, the alarm beeps. If this happens during printing, stop printing at once. If not printing,
disconnect the USB connection cable.
Connect the camera to a printer via the USB connection cable A
(supplied).
• When the camera is connected to the printer, the cable disconnect prohibit icon [å]
appears. Do not disconnect the USB cable while [å] is displayed.
Press 3/4 to select [PictBridge(PTP)], and then press [MENU/SET].
Note
• Do not use any other USB connection cables except the supplied one.
Use of cables other than the supplied USB connection cable may cause malfunction.
• Before connecting or disconnecting the AC adaptor (optional), turn the camera off.
• Before inserting or removing a card, turn the camera off, and disconnect the USB connection
cable.
• Motion pictures cannot be printed out.

Panasonic Lumix DMC-FS16 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Supported aspect ratios	16:9
Maximum image resolution	4320 x 3240 pixels
Digital zoom	4 x
Combined zoom	33.8 x
Focal length range	5 - 25 mm
Lens structure (elements/groups)	6/5
Interface	USB 2.0
Digital SLR	No
Power supply type	AC/DC
HDMI ports quantity	0
Aperture range (F-F)	3.1 - 6.5
Camera shutter speed	8 - 1/1600 s
Compatible operating systems	-
Focal length (35mm film equivalent)	28 - 112 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Spot Auto Focus
ISO sensitivity	80, 100, 200, 400, 800, 1600, 6400, Auto
Camera shutter interval	0.9 s
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 1.6 m
Flash range (wide)	0.4 - 3.3 m
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Maximum video resolution	1280 x 720 pixels
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
USB version	2.0
Scene modes	Beach, Candlelight, Fireworks, Night portrait, Panorama, Portrait, Self-portrait, Snow, Sports, Sunset
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Camera playback	movie, slide show, thumbnails
Product color	Red
Battery capacity	660 mAh
Power requirements	110-240V
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	18.8 mm
Width	94.3 mm
Height	53.5 mm
Weight	118 g
