Page #117 background imageLoading...
Page #117 background image
- 117 -
Others
Store the battery in a cool and dry place with a relatively stable temperature: [Recommended
temperature: 15 oC to 25 oC (59 oF to 77 oF), Recommended humidity: 40%RH to 60%RH]
Always remove the battery and the card from the camera.
If the battery is left inserted in the camera, it will discharge even if the camera is turned off. If
the battery continues to be left in the camera, it will discharge excessively and may become
unusable even if charged.
When storing the battery for a long period of time, we recommend charging it once a year.
Remove the battery from the camera and store it again after it has completely discharged.
We recommend storing the camera with a desiccant (silica gel) when you keep it in a closet or
a cabinet.
Recorded data may be damaged or lost if the camera breaks down due to inappropriate
handling. Panasonic will not be liable for any damage suffered due to loss of recorded
data.
When you use a tripod, make sure the tripod is stable when this unit is attached to it.
You may not be able to remove the card or the battery when using a tripod or unipod.
Make sure that the screw on the tripod or unipod is not at an angle when attaching or detaching
the camera. You may damage the screw on the camera if you use excessive force when
turning it. Also, the camera body and the rating label may be damaged or scratched if the
camera is attached too tightly to the tripod or unipod.
Read the operating instructions for the tripod or unipod carefully.
Some tripods or unipods cannot be attached when the DC coupler (optional) and AC adaptor
(optional) are connected.
(DMC-FS18) (DMC-FS16) (DMC-FS14)
Some tripods or unipods may block the speaker, making it difficult to hear operating sounds etc.
When not using the camera for a long period of time
About the picture data
About tripods or unipods

Table of Contents

Other manuals for Panasonic Lumix DMC-FS16

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS16 and is the answer not in the manual?

Panasonic Lumix DMC-FS16 Specifications

General IconGeneral
Megapixel14.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.33 \
Supported aspect ratios16:9
Maximum image resolution4320 x 3240 pixels
Digital zoom4 x
Combined zoom33.8 x
Focal length range5 - 25 mm
Lens structure (elements/groups)6/5
InterfaceUSB 2.0
Digital SLRNo
Power supply typeAC/DC
HDMI ports quantity0
Aperture range (F-F)3.1 - 6.5
Camera shutter speed8 - 1/1600 s
Compatible operating systems-
Focal length (35mm film equivalent)28 - 112 mm
Focus adjustmentAuto
Auto focusing (AF) modesSpot Auto Focus
ISO sensitivity80, 100, 200, 400, 800, 1600, 6400, Auto
Camera shutter interval0.9 s
Flash modesauto, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 1.6 m
Flash range (wide)0.4 - 3.3 m
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum video resolution1280 x 720 pixels
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
Viewfinder typeNot available
USB version2.0
Scene modesBeach, Candlelight, Fireworks, Night portrait, Panorama, Portrait, Self-portrait, Snow, Sports, Sunset
Photo effectsBlack&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackmovie, slide show, thumbnails
Product colorRed
Battery capacity660 mAh
Power requirements110-240V
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth18.8 mm
Width94.3 mm
Height53.5 mm
Weight118 g
