Others
103
∫ Recording in simple mode
1 Flash (P41)
2 Focus indication (P32)
3 Picture mode (P36)
: Jitter alert indication (P34)
4 Battery indication (P14)
5 Picture remain
6 Recording indication
7 Card access indication (P17)
8 AF area (P32)
9 Backlight compensation indication
(P38)
10 Current date and time (
P22
)
• This is displayed for about 5 seconds
when turning the camera on, setting
the clock and after switching from the
playback mode to the simple mode.
11 Compensating backlight ON indication
(P38)
12 Self-timer (P44)
13 AF assist lamp (P75)
14 Zoom (P40)
15 Burst (P47)
8
W
T 1X
BACKLIGHT
123 4
9
10
11
13
14
15
12
5
6
7
8
10:00 DEC. 1.2004
