Preparation
20
Attaching the Lens Hood
In bright sunlight or backlight, the lens hood
will minimize lens flare and ghosting.
The lens hood cuts off excess lighting and
improves the picture quality.
• Check that the camera is turned off and
that the lens is retracted.
• Close the flash.
1 1 Adjust A on the lens hood
adaptor to [UNLOCK].
2 Place the camera upside down.
Align [UNLOCK] to B on the
camera and then attach the
lens hood adaptor to the
camera.
2 Rotate the ring C to the direction
of the arrow until [LOCK] is
adjusted to A on the adaptor.
• Rotate the ring until it clicks.
3 1 Place the camera right side up.
Adjust D on the lens hood to
E on the lens hood adaptor.
2 Rotate the lens hood from E to
F.
[
UNLOCK
]
[
LOCK
]
FZ3-PP.book 20 ページ ２００４年６月２１日 月曜日 午後７時６分
To Next Page
