Panasonic Lumix DMC-FZ30PP Service Manual

17
Attribute Main item Sub item Error code Contents (Upper)
High 4 bits Low 4 bits Check point (Lower)
LENS Lens drive OIS 1800 1000 PSD (X) error. Hall element (X axis) position detect error in OIS unit.
OIS Unit
2000 PSD (Y) error. Hall element (Y axis) position detect error in OIS unit.
OIS Unit
3000 GYRO (X) error. Gyro (IC7102: X axis) detect error on Main C.B.A..
IC7102 (Gyro element) or IC6001 (VENUS 2)
4000 GYRO (Y) error. Gyro (IC7101: Y axis) detect error on Main C.B.A..
IC7101 (Gyro element) or IC6001 (VENUS 2)
5000 MREF error (Reference voltage error).
IC7002 (LENS drive) or IC6001 (VENUS 2)
6000 Drive voltage (X) error.
VENUS 2 AD value error, LENS Unit, LENS flex breaks etc.
7000 Drive voltage (Y) error.
VENUS 2 AD value error, LENS Unit, LENS flex breaks etc.
C.B./Zoom 0100 HP Low detect error (C.B. encoder (full retract) always Low detect).
FP9008-(28) signal line or IC6001 (VENUS 2)
0200 HP High detect error (C.B. encoder (full retract) always High detect).
FP9008-(28) signal line or IC6001 (VENUS 2)
0300 ENC1 detect error (C.B. motor encoder detect error).
0400 ENC2 detect error (C.B. motor encoder detect error).
Zoom 0010 HP Low detect error (Zoom encoder always Low detect error).
0020 HP High detect error (Zoom encoder always High detect error).
0030 ENC1 detect error (Zoom encoder detect error).
0040 ENC2 detect error (Zoom encoder detect error).
Focus 0001 HP Low detect error (Focus encoder always Low detect error).
FP9008-(28) signal line or IC6001 (VENUS 2)
0002 HP High detect error (Focus encoder always High detect error).
FP9008-(28) signal line or IC6001 (VENUS 2)
0003 MR A aspect output error
FP9008-(32) signal line or IC6001 (VENUS 2)
0004 MR B aspect output error
FP9008-(30) signal line or IC6001 (VENUS 2)
Lens 1801 0000 Power ON time out error.
Lens drive system
1802 0000 Power OFF time out error.
Lens drive system
Adj.History OIS 1900 2000 OIS adj. Yaw direction amplitude error (small)
3000 OIS adj. Pit direction amplitude error (small)
4000 OIS adj. Yaw direction amplitude error (large)
5000 OIS adj. Pit direction amplitude error (large)
6000 OIS adj. MREF error
7000 OIS adj. time out error
8000 OIS adj. Yaw direction off set error
9000 OIS adj. Pit direction off set error
A000 OIS adj. Yaw direction gain error
B000 OIS adj. Pit direction gain error
C000 OIS adj. Yaw direction position sensor error
D000 OIS adj. Pit direction position sensor error
E000 OIS adj. other error
HARD VENUS A/D Flash 2800 0000 Flash charging error.
IC6001-(13) signal line or Flash charging circuit
FLASH ROM
(EEPROM
Area)
FLASH ROM
(EEPROM
Area)
2B00 0001 EEPROM read error
IC6002 (FLASH ROM)
0002 EEPROM write error
IC6002 (FLASH ROM)
SYSTEM RTC 2C00 0001 SYSTEM IC initialize failure error
Communication between IC6001 (VENUS 2) and IC9101 (SYSTEM)
