VQT2G40 (ENG)
10
Before Use
Names of the Components
1 Lens
2Flash
3 Self-timer indicator
AF assist lamp
4 Flash open button
5 Diopter adjustment dial
6 Viewfinder
7 Speaker
8 Motion picture button
9 [AF/AE LOCK] button
10 Joystick
The joystick is operated in two different ways: it can be moved in the up, down, left
and right directions to perform an operation, or it can be pressed to select. In these
operating instructions, it is pictured as shown in the figure below or described with
3/4/2/1.
Example: When the joystick is moved
toward 2 (left)
Place your finger on the right side of the
joystick, and move the joystick toward
the left.
or Move 2
Push the joystick straight in.
or Press
123
DMC-FZ38&FZ35P-VQT2G40_eng.book 10 ページ ２００９年６月３０日 火曜日 午後６時３３分
