13
Preparation
(ENG) VQT5D62
∫ Lens
• The interchangeable lens (H-FS12032) does not have a focus ring, but you can use manual
focus by operating the camera. Refer to P26 for details.
Operate the touch screen directly with your finger.
∫ Touch
To touch and release the touch screen.
• When selecting features using the touch screen, be sure to
touch the centre of the desired icon.
∫ Drag
A movement without releasing the touch screen.
This can also be used to move to the next image during
playback, etc.
∫ Pinch (enlarge/reduce)
Pinch the touch panel apart (enlarge) or together
(reduce) with two fingers.
H-FS12032
1 Lens surface
2Tele
3 Zoom ring
4Wide
5 Contact point
6 Lens fitting mark
Touch screen (capacitive)
2.0X2.0X
2.0X
DMC-GM1KGH-VQT5D62_eng.book 13 ページ ２０１３年１０月１８日 金曜日 午後４時７分
To Next Page
