Panasonic Lumix DMC-LX100 Operating Instructions For Advanced Features

307
SQW0038
Others
Menu list
[Peaking]
When you perform Manual Focus operation, this function
automatically adds colour to the portions of the image that are in
focus.
→130
[Histogram] Sets whether to display the histogram. →64
[Guide Line] Sets the pattern of the guidelines to be displayed while recording. →65
[Highlight]
Flashes the overexposed areas in black and white during [Auto
Review] or playback.
→72
[Zebra Pattern]
Displays the area, where overexposure may occur, using a zebra
pattern.
→166
[Monochrome Live
View]
You can display the recording screen in black and white. →167
[Constant Preview]
(M Mode)
Allows the effects of the aperture value and shutter speed on the
recording screen to be checked when [Manual Exposure] Mode
is set.
→87
[Expo.Meter] Sets whether to display the exposure meter. →81
[Dial Guide] Sets whether to display the operation guide. →18
[LVF Disp.Style] Sets the viewfinder display method. →63
[Monitor Disp. Style] Switching the monitor display method. →62
[Monitor Info. Disp.] Switches the recording information screen of the monitor. →65
[Rec Area]
Switching the angle of view setting used for recording still pictures
and motion pictures.
→192
[Remaining Disp.]
Switching the display between the number of recordable pictures
that you can take and the available recording time.
→28
[Auto Review]
Set the time to display the pictures you have taken after taking still
pictures.
→57
[Fn Button Set] You can assign frequently-used functions to particular buttons. →37
[Zoom lever] Switches the zoom lever operation setting. →175
[Control Ring] You can assign frequently-used functions to control ring. →40
[Zoom Resume] Retaining the zoom position when the camera is turned off. →175
[Q.MENU] Switches the method for setting Quick Menu items. →34
[iA Button Switch]
Changes the operation method of the [iA] button used for switching
to [Intelligent Auto] Mode.
→75
[Video Button] Enabling/disabling the motion picture button. →192
[Eye Sensor]
Setting the sensitivity of the eye sensor or setting to switch the
display between the viewfinder and monitor.
→55

Panasonic Lumix DMC-LX100 Specifications

General

Megapixel	12.8 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4112 x 3088 pixels
Still image resolution(s)	[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom	4 x
Optical zoom	3.1 x
Focal length range	10.9 - 34 mm
Maximum aperture number	16
Minimum aperture number	1.7
Lens structure (elements/groups)	11/8
Maximum focal length (35mm film equiv)	75 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 8.5 m
Flash range (wide)	0.6 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	921000 pixels
Magnification	1.39 x
Viewfinder screen size	0.38 \
USB version	-
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Image processor	Venus
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF, Exif 2.3, RAW
Image quality adjustment	Colour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	350 shots
Product color	Silver
Cables included	AC, USB
Bundled software	PHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader

Weight and Dimensions

Depth	55 mm
Width	114.8 mm
Height	66.2 mm
Weight	351 g
Weight (including battery)	393 g
