11
SQT1395 (ENG)
Preparations
1 Shutter button (→17)
2
Zoom lever (→16)
3
Motion picture button (→34)
4
Rear dial (→21)
5
Camera [ON/OFF] switch
6
Mode dial (→18)
7
Stereo microphone
8
Flash open lever
9
Flash
10
Strap eyelet
• To prevent dropping, be sure to
attach the supplied strap and fit it to
your wrist.
11
Aperture ring (→21)
12
Control ring (→21)
13
Lens barrel
14
Lens
15
Self-timer indicator/AF Assist Lamp
16
Charging lamp (→13)/
Wi-Fi
®
connection lamp
17
[ ] ([Post Focus]) button (→30)/
[Fn2] button
18
[Q.MENU/
] (Cancel) button/
[
] (Delete) button (→38)/
[Fn3] button
• You can easily call some of the menu
items and set them during recording.
19
[
] (4K photo mode) button (→26)/
[Fn1] button
20
[ ] (Playback) button (→38)
21
Cursor button (→19)
22
[MENU/SET] button
23
[DISP.] button
• Use this to change display.
24
[HDMI] socket
25
[USB/CHARGE] socket (→13)
26
Release lever (→12)
27
DC coupler cover (→61)
28
Card/Battery door (→12)
29
Tripod mount
• Do not attach this unit to tripods that
have screws with a length of 5.5 mm
(0.22 inch) or more. Doing so may
damage this unit or the unit may not be
secured properly on the tripod.
30
Touch screen (→22)/monitor (→51)
31
Speaker
●
Always use a genuine Panasonic
AC adaptor (DMW-AC10E: optional).
(→61)
When using an AC adaptor (DMW-
AC10E: optional), ensure that the
Panasonic DC coupler (DMW-
DCC15A: optional) and AC adaptor
(DMW-AC10E: optional) are used.
The optional DC coupler (DMW-
DCC15) cannot be used.
●
[Fn4] to [Fn8] (→19) are touch icons.
They are displayed by touching the
[
] tab on the recording screen.
