Panasonic Lumix DMC-LX15 Basic Operating Instructions

13
SQT1395 (ENG)
Preparations
• The battery that can be used with this unit is DMW-BLH7E.
• The battery is not charged when the camera is shipped. Charge the battery
before use.
• We recommend charging in a location where the ambient temperature is
between 10 °C and 30 °C (50 °F to 86 °F).
Insert the battery into the camera.
Make sure that the camera is turned off.
[USB/CHARGE] socket
• This terminal is located at the bottom when the
camera is in an upright position.
• Always check the direction of the pins and hold the plug straight to insert
or remove it. (If the cable is inserted in the wrong direction, the pins could
become deformed and cause faulty operation.) Also, do not insert into the
wrong socket. Doing so may cause damage to this unit.
Charging lamp
USB connection cable
(supplied)
AC adaptor (supplied)
To the electrical outlet
Computer
Getting ready:
Turn on the computer.
Charging the battery

Panasonic Lumix DMC-LX15 Specifications

General

Megapixels	20.1 MP
Lens	Leica DC Vario-Summilux
Aperture	f/1.4-2.8
Optical Zoom	3x
Connectivity	Wi-Fi
LCD Screen Resolution	1, 040, 000 dots
Continuous Shooting	10 fps
Built-in Flash	Yes
Battery Life	Approx. 260 shots
ISO Sensitivity	ISO 125-12800 (expandable to 80-25600)
Video Recording	4K UHD 30p, Full HD 60p
Display	3.0-inch TFT LCD
Focal Length	24-72mm (35mm equivalent)
Shutter Speed	60 - 1/4000 sec
Focus Points	49 points
Battery Type	Li-ion Battery Pack (7.2V, 680mAh)
Dimensions	105.5 x 60 x 42 mm
Weight	310 g (with battery and SD card)
Sensor Type	1-inch High Sensitivity MOS Sensor
Image Stabilization	5-axis Hybrid O.I.S.+
