DMC-LX5EG-K vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
## VEP56112A MAIN P.C.B. 1 (EXCEPT EG,EP,EF,EB) (RTL R8002 ERJ2GEJ104X M.RESISTOR CH 1/16W 100K 1 [PAVCSG]
(RTL) E.S.D. R8006 ERJ6GEYJ514V M.RESISTOR CH 1/10W 514K 1 [PAVCSG]
## VEP56112B MAIN P.C.B. 1 EG,EP,EF,EB (RTL) E.S.D. R8007 ERJ3GEYJ620V M.RESISTOR CH 1/10W ޓ62 1 [PAVCSG]
## VEP50067A GYRO P.C.B. 1 (RTL) E.S.D. R8008 ERJ6GEYJ514V M.RESISTOR CH 1/10W 514K 1 [PAVCSG]
## VEP51028A BATTERY P.C.B. 1 (RTL) E.S.D. R8013 ERJ2RHD1621X M.RESISTOR CH W K 1 [PAVCSG]
## VEP59089A LVF P.C.B. 1 (RTL) [PAVCSG] E.S.D. R8021 ERJ2GEJ473X M.RESISTOR CH 1/16W 47K 1 [PAVCSG]
## VEP58128A FLASH P.C.B. 1 (RTL) [PAVCSG] E.S.D. R8032 D1BD4703A119 RESISTOR 1 [PAVCSG]
## VEP59088A TOP P.C.B. 1 (RTL) [PAVCSG] E.S.D.
## VEK0R03 CCD UNIT 1 T8001 G5D1A0000080 TRANSFORMER 1 [PAVCSG]
## VEP50067A GYRO P.C.B. (RTL) E.S.D. ## VEP59088A TOP P.C.B. (RTL) [PAVCSG] E.S.D.
C7201 F1H0J475A010 C.CAPACITOR CH 6.3V 4.7U 1 C9952 F1G1C1030008 C.CAPACITOR CH 16V 0.01U 1 [PAVCSG]
C7202 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1 C9953 F1G1E332A059 C.CAPACITOR CH 25V 3300P 1 [PAVCSG]
C9981 F1G1H470A565 C.CAPACITOR CH 50V 47P 1 [PAVCSG]
FP7201 K1MY04BA0370 CONNECTOR 4P 1
D9921 B3ADB0000142 DIODE 1 [PAVCSG] E.S.D.
IC7201 L2ES00000021 IC 1 E.S.D. D9951 B0BC8R2A0266 DIODE 1 [PAVCSG] E.S.D.
D9952 B2ABDR000010 DIODE 1 [PAVCSG] E.S.D.
FP9901 K1MY04BA0370 CONNECTOR 4P 1 [PAVCSG]
## VEP51028A BATTERY P.C.B. (RTL) E.S.D. FP9951 K1MN10BA0209 CONNECTOR 10P 1 [PAVCSG]
FP9971 K1MY19BA0235 CONNECTOR 19P 1 [PAVCSG]
C7301 F1H0J475A010 C.CAPACITOR CH 6.3V 4.7U 1
C7302 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1 LB9981 J0JCC0000415 FILTER 1 [PAVCSG]
 F9201 ERBSE2R00U FUSE 32V 2.0A 1 PS9901 K1KB40AA0094 CONNECTOR 40P 1 [PAVCSG]
FP9201 K1MY16BA0370 CONNECTOR 16P 1 Q9951 B1CFHC000005 TRANSISTOR 1 [PAVCSG] E.S.D.
IC7301 L2ES00000022 IC 1 E.S.D. QR9951 B1GKCFJN0003 TRANSISTOR-RESISTOR 1 [PAVCSG] E.S.D.
P9201 K4ZZ04000051 CONNECTOR 4P 1 R9901 ERJ2GEJ432X M.RESISTOR CH 1/10W 4.3K 1 [PAVCSG]
R9902 ERJ2GEJ822X M.RESISTOR CH 1/10W 8.2K 1 [PAVCSG]
R7301 ERJ3GEY0R00 M.RESISTOR CH 1/10W 0 1 R9903 ERJ2GEJ242X M.RESISTOR CH 1/16W 2.4K 1 [PAVCSG]
R7302 ERJ3GEY0R00 M.RESISTOR CH 1/10W 0 1 R9904 ERJ2GEJ243X M.RESISTOR CH 1/16W 24K 1 [PAVCSG]
R9201 ERJ2GEJ512X M.RESISTOR CH 1/16W 5.1K 1 R9905 ERJ2GEJ242X M.RESISTOR CH 1/16W 2.4K 1 [PAVCSG]
R9202 D0YAR0000007 M.RESISTOR CH 1/10W 0 1 R9906 ERJ2GEJ432X M.RESISTOR CH 1/10W 4.3K 1 [PAVCSG]
R9907 ERJ2GEJ822X M.RESISTOR CH 1/10W 8.2K 1 [PAVCSG]
ZB9201 K3ZZ00200042 BATTERY HOLDER 1 R9908 ERJ2GEJ243X M.RESISTOR CH 1/16W 24K 1 [PAVCSG]
R9909 ERJ2GEJ153X M.RESISTOR CH 1/16W 15K 1 [PAVCSG]
R9910 ERJ2GEJ472X M.RESISTOR CH 1/10W 4.7K 1 [PAVCSG]
R9911 ERJ2GE0R00X M.RESISTOR CH 1/16W 0 1 [PAVCSG]
## VEP59089A LVF P.C.B. (RTL) [PAVCSG] E.S.D. R9921 ERJ3GEYJ270V M.RESISTOR CH 1/10W 27 1 [PAVCSG]
R9922 ERJ3GEYJ270V M.RESISTOR CH 1/10W 27 1 [PAVCSG]
FP2501 K1MY19BA0235 CONNECTOR 19P 1 [PAVCSG] R9951 ERJ2GEJ473X M.RESISTOR CH 1/16W 47K 1 [PAVCSG]
R9952 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG]
JK2501 K1FY230E0002 JACK 1 [PAVCSG] R9954 ERJ2GEJ471X M.RESISTOR CH 1/10W 470 1 [PAVCSG]
R9955 ERJ6GEYJ106V M.RESISTOR CH 1/10W 10M 1 [PAVCSG]
R2501 ERJ2GE0R00X M.RESISTOR CH 1/16W 0 1 [PAVCSG] R9956 ERJ6GEYJ106V M.RESISTOR CH 1/10W 10M 1 [PAVCSG]
R9957 ERJ2GEJ331X M.RESISTOR CH 1/16W 330 1 [PAVCSG]
R9958 ERJ2GEJ331X M.RESISTOR CH 1/16W 330 1 [PAVCSG]
R9959 ERJ2GEJ331X M.RESISTOR CH 1/16W 330 1 [PAVCSG]
## VEP58128A FLASH P.C.B. (RTL) [PAVCSG] E.S.D.
S9901 K0G199A00010 SWITCH 1 [PAVCSG]
C8001 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 [PAVCSG] S9902 K0F212A00003 SWITCH 1 [PAVCSG]
C8006 F1K2E4730005 C.CAPACITOR 250V 0.047U 1 [PAVCSG] S9903 K0D112B00145 SWITCH 1 [PAVCSG]
C8007 F1G1H220A565 C.CAPACITOR CH 50V 22P 1 [PAVCSG] S9904 K0L1CB000003 SWITCH 1 [PAVCSG]
C8009 F1J0J106A020 C.CAPACITOR CH 6.3V 10U 1 [PAVCSG] S9905 K0F111A00541 SWITCH 1 [PAVCSG]
C8501 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1 [PAVCSG]
D8002 B0ECFR000003 DIODE 1 [PAVCSG] E.S.D.
## VEK0R03 CCD UNIT
 F8001 ERBSE1R25U FUSE 32V 1.25A 1 [PAVCSG]
C3101 F1J1C106A059 C.CAPACITOR CH 16V 10U 1
FP8001 K1MY14BA0370 CONNECTOR 14P 1 [PAVCSG] C3103 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1
IC8001 C0ZBZ0001710 IC 1 [PAVCSG] E.S.D. Q3101 C1AB00003341 IC 1 E.S.D.
IC8501 B4ABC0000029 IC 1 [PAVCSG] E.S.D.
R3101 ERJ2GEJ124 M.RESISTOR CH 1/16W 120K 1
P8001 K1KA02B00292 CONNECTOR 2P 1 [PAVCSG] R3102 ERJ2GEJ104 M.RESISTOR CH 1/10W 100K 1
P8002 K1KA02ZA0001 CONNECTOR 2P 1 [PAVCSG] R3103 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 1
Q8001 B1JBLP000022 TRANSISTOR 1 [PAVCSG] E.S.D. TH3101 D4CC11030026 THERMISTORS 1
S-18
