DMC-LX5EG-K vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
B9 VHD2206 SCREW 1 (-K)
1 VEP56112B MAIN P.C.B. 1 EG,EP,EF,EB (RTL) E.S.D. B9 VHD2205 SCREW 1 (-W)
1 VEP56112A MAIN P.C.B. 1 (EXCEPT EG,EP,EF,EB) B10 VHD2206 SCREW 1 (-K)
(RTL) E.S.D. B10 VHD2205 SCREW 1 (-W)
2 VGK3657 FRONT GRIP 1 (-K) B11 VHD2206 SCREW 1 (-K)
2 VGK3698 FRONT GRIP 1 (-W) B11 VHD2205 SCREW 1 (-W)
3 VYK4J22 FRONT CASE UNIT 1 (-K) B12 VHD2206 SCREW 1 (-K)
3 VYK4J23 FRONT CASE UNIT 1 (-W) B12 VHD2205 SCREW 1 (-W)
4 VMP9735 FRONT PLATE 1 B13 VHD2206 SCREW 1 (-K)
5 VYK4F35 LENS ORNAMENT UNIT 1 (-K) B13 VHD2205 SCREW 1 (-W)
5 VYK4G90 LENS ORNAMENT UNIT 1 (-W) B14 VHD2206 SCREW 1 (-K)
5-1 VEK0Q61 AF/MF-ASPECT FPC 1 B14 VHD2205 SCREW 1 (-W)
5-2 VGK3662 LENS RING FRONT 1 (-K) B15 VHD2206 SCREW 1 (-K)
5-2 VGK3696 LENS RING FRONT 1 (-W) B15 VHD2205 SCREW 1 (-W)
6VGQ0A50CAPTON TAPE1B16VHD2208SCREW1(-K)
9VYK4G35LCD UNIT1B16VHD2207SCREW1(-W)
10 VYK4G36 LCD PANEL UNIT 1 B17 VHD2208 SCREW 1 (-K)
11VYK4G37REAR CASE UNIT1(-K) B17VHD2207SCREW1(-W)
11 VYK4G38 REAR CASE UNIT 1 (-W) B18 VHD2259 SCREW 1
11-1 VGK3659 GRIP PIECE REAR 1 (-K) B19 VHD2259 SCREW 1
11-1VGK3709GRIP PIECE REAR1(-W) B20VHD2259SCREW1
11-2 VGL1276 REAR PANEL LIGHT 1 B21 VHD2259 SCREW 1
11-3VGU0G58CURSOR BUTTON1B23XQN14+BJ75FNSCREW1
12 VGK3660 LVF JACK HOLDER 1 B24 XQN14+BJ75FN SCREW 1
13 L0AA01A00054 SPEAKER 1 B25 XQN14+BJ75FN SCREW 1
14 ML-421S/ZTK BUTTON BATTERY 1 [ENERGY] (B9201) B26 VHD1812 SCREW 1
15 VEP50067A GYRO P.C.B. 1 (RTL) E.S.D. B27 VHD1812 SCREW 1
16 VEP51028A BATTERY P.C.B. 1 (RTL) E.S.D. B28 VHD1812 SCREW 1
17 VKF4733 JACK DOOR 1 (-K) B52 VHD2198 SCREW 1 [PAVCSG]
17 VKF4734 JACK DOOR 1 (-W) B53 XQN14+BJ4FJK SCREW 1 [PAVCSG]
18 VMB3962 BATTERY LOCK SPRING 1 B54 XQN14+BJ4FJK SCREW 1 [PAVCSG]
19 VMB4443 BATTERY OUT SPRING 1 B55 XQN14+BJ4FJK SCREW 1 [PAVCSG]
20 VMP9737 FRAME 1 B56 XQN14+BJ4FJK SCREW 1 [PAVCSG]
21 VMP9738 BATTERY CASE 1
22 VMS8049 JACK DOOR SHAFT 1
23 VWJ2191 MAIN-BATTERY-JOINT FPC 1
24 VWJ2198 MAIN-GYRO-JOINT FPC 1
25 VMC2008 SHOE SPRING 1
26 VMP9740 TORIPOD 1
27 VYF3287 HOTSHOE COVER 1
28 VGQ0N89 SPEAKER TAPE 1
29 VGQ0M00 BATTERY LOCK KNOB 1
50 K0RC01100005 DIAL UNIT 1 [PAVCSG]
51 VEK0Q99 HOT SHOE UNIT 1 [PAVCSG]
52 VEP58128A FLASH P.C.B. 1 (RTL) [PAVCSG] E.S.D.
53 VEP59088A TOP P.C.B. 1 (RTL) [PAVCSG] E.S.D.
54 VEP59089A LVF P.C.B. 1 (RTL) [PAVCSG] E.S.D.
55 VYK4J20 TOP CASE UNIT 1 (-K) [PAVCSG]
55 VYK4J21 TOP CASE UNIT 1 (-W) [PAVCSG]
56 VGL1290 AF PANEL LIGHT 1 [PAVCSG]
57 VGQ0H34-A COUPLING PLATE 1 [PAVCSG]
58 VGQ0Q88 DPR SHEET 1 [PAVCSG]
59 VKH0457 STRAP HOLDER (L) 1 [PAVCSG]
60 VKH0458 STRAP HOLDER (R) 1 [PAVCSG]
61 VMP9739 SHIELD PLATE 1 [PAVCSG]
62 VMP9742 TOP PLATE 1 [PAVCSG]
63 VWJ2192 MAIN-LVF JOINT FPC 1 [PAVCSG]
64 VYK4K22 FLASH UNIT 1 (-K) [PAVCSG]
64 VYK4K23 FLASH UNIT 1 (-W) [PAVCSG]
65 VYF3364 BATTERY DOOR UNIT 1 (-K) [PAVCSG]
65 VYF3365 BATTERY DOOR UNIT 1 (-W) [PAVCSG]
65-1 VMB4332 BATTERY DOOR SPRING 1 [PAVCSG]
65-2 VMS8040 BATTERY DOOR SHAFT 1 [PAVCSG]
66 VGQ0N71 FL PCB COVER 1 [PAVCSG]
67 VGQ0N77 FL TAPE (A) 1 [PAVCSG]
68 VWJ2190 MAIN-FLASH JOINT FPC 1 [PAVCSG]
69 F2A2F9000005 E.CAPACITOR 1 [PAVCSG] (C8003)
70 VMB4393 EARTH SPRING 1 [PAVCSG]
B1 RHD14153 SCREW 1
B2 RHD14153 SCREW 1
B3 RHD14153 SCREW 1
B4 RHD14153 SCREW 1
B5 VHD1803 SCREW 1
B6 VHD2207 SCREW 1
B7 VHD1678 SCREW 1
B8 VHD1678 SCREW 1
S-19
