DMC-LX5EG-K vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
100 VXW1158 LENS UNIT (W/O CCD) 1
103 VEK0R03 CCD UNIT 1
111 VMB4405 CCD SPRING 1
112 VMB4405 CCD SPRING 1
115 L6DAYYYC0001 ZOOM MOTOR 1
117 VXP3484 1ST LENS FRAME UNIT 1
118 VXP3486 1ST DRIVE FRAME UNIT 1
119 VDW2123 BOTH SIDES CAM FRAME 1
120 VXP3487 2ND LENS FRAME UNIT 1
121 VXP3493 3RD LENS FRAME UNIT 1
122 VDW2124 2ND/3RD DIRECT FRAME 1
123 VXQ1930 FIX FRAME UNIT 1
125 VXQ1931 MASTER FLANGE UNIT 1
125-1 L6HAYYYC0029 FOCUS MOTOR 1
125-2 VMB4403 FOCUS SPRING 1
B101 VHD2107 SCREW 1
B102 VHD2107 SCREW 1
B103 VHD2107 SCREW 1
B104 XQN14+BJ4FNK SCREW 1
B105 XQN14+BJ4FNK SCREW 1
B107 XQN14+BJ4FNK SCREW 1
B108 XQN14+BJ4FNK SCREW 1
B109 XQN14+BJ4FNK SCREW 1
B110 XQN14+BJ4FNK SCREW 1
S-20
To Next Page
