(ENG) VQT4J01 11
LCD monitor
[ND/FOCUS] lever
Rear dial
Status indicator
Cursor buttons
[MENU/SET]
[Q.MENU]/[
]
(Delete/Cancel) button
[DISP.] button
Flash open switch
Hot shoe (Hot shoe cover)
[AF/AE LOCK]
button
Playback button
• Switches
between
recording mode
and playback
mode.
[HDMI] socket
[AV OUT/
DIGITAL] socket
*
Do not attach to a tripod with a 5.5 mm or longer screw. Doing so may
damage this unit.
●
Always use a genuine Panasonic AC adaptor (DMW-AC5E:
optional).
●
When using an AC adaptor, ensure that the Panasonic DC coupler
(DMW-DCC7: optional) and AC adaptor (DMW-AC5E: optional) are
used.
●
Keep the hot shoe cover out of reach of children to prevent
swallowing.
●
Be sure to attach the hot shoe cover when the hot shoe is not in
use.
Tripod mount
*
• Ensure that the tripod is stable.
Card/Battery door
Release lever
DC coupler cover
Speaker
To Next Page
