- 100 -
Usage cautions and notes
Lens
If lens is dirty:
Images may appear slightly white if lens is dirty (fingerprints, etc.). Turn the power on, hold the
extracted lens barrel with your fingers, and gently wipe the lens surface with a soft, dry cloth.
Do not leave the lens exposed to direct sunlight.
Do not touch the lens barrier, as this may damage lens. Be careful when removing camera from
bag, etc.
When using a tripod or unipod
Do not apply excessive force or tighten screws when they are crooked. (This may damage the
camera, screw hole, or label.)
Ensure that the tripod is stable. (Refer to the tripod instructions.)
You may not be able to remove the card or the battery when using a tripod or unipod.
Personal Information
If birthdays are set in [Baby] Mode, keep in mind that the camera and recorded pictures will contain
personal information.
Disclaimer
Data containing personal information can be altered or lost due to malfunction, static electricity,
accidents, breakdowns, repairs, or other operations.
Panasonic will not be liable for any damage that occurs, direct or indirect, as a result of the
alteration or loss of data containing personal information.
When ordering repairs or transferring/disposing of the camera
To protect your personal information, please reset the settings. (→37)
If any pictures are contained in the built-in memory, copy (→77) them to a memory card if
necessary, and then format (→39) the built-in memory.
Remove the memory card from the camera.
When ordering repairs, the built-in memory and other settings may be returned to the initial
purchase state.
If the above operations cannot be performed because of a camera malfunction, consult with the
dealer or nearest Service Centre.
When transferring or disposing of your memory card, see “When disposing of/transferring
memory cards” in the previous section.

Table of Contents

Other manuals for Panasonic Lumix DMC-S2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-S2 and is the answer not in the manual?

Panasonic Lumix DMC-S2 Specifications

General IconGeneral
Megapixel14.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels14.5 MP
Image sensor size1/2.33 \
Image formats supportedJPG
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4320 x 3240 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 3232 x 3232, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Optical zoom4 x
Extra/Smart zoom8 x
Focal length range5 - 20 mm
Maximum aperture number6.5
Minimum aperture number3.1
Number of aspheric elements8
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)132 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto
Auto Focus (AF) points23
Auto focusing (AF) modesMulti Point Auto Focus, Single Auto Focus
Closest focusing distance0.05 m
ISO sensitivity100, 200, 400, 800, 1600, 6400
ISO sensitivity (max)1600
ISO sensitivity (min)100
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Flash modesForced off, Forced on, Red-eye reduction, Slow synchronization, Soft
Flash range (tele)1 - 1.6 m
Flash range (wide)0.4 - 3.3 m
Power source typeBattery, USB
Optical viewfinderNo
Scene modesChildren, Night portrait, Panorama, Portrait, Sports, Sunset
Image editingResizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackSingle image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF 2.0, Exif 2.3
Video resolutions320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate30 fps
Video formats supportedM-JPEG
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC
Audio systemMono
Memory slots1
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
USB version2.0
Product colorWhite
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 8.0 Adobe Reader
Battery voltage3.6 V
Battery life (CIPA standard)280 shots
Weight and Dimensions IconWeight and Dimensions
Depth20.6 mm
Width97.9 mm
Height56.6 mm
Weight95 g
Weight (including battery)112 g
