- 98 -
Usage cautions and notes
When in use
Camera may become warm if used for long periods of time, but this is not a fault.
Keep this unit as far away as possible from electromagnetic equipment (such as microwave
ovens, TVs, video games etc.).
If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be disrupted
by electromagnetic wave radiation.
Do not use this unit near cell phones because doing so may result in noise adversely affecting the
pictures and/or sound.
Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields created
by speakers or large motors.
Electromagnetic wave radiation generated by microprocessors may adversely affect this unit,
disturbing the pictures and/or sound.
If this unit is adversely affected by electromagnetic equipment and stops functioning properly, turn
this unit off and remove the battery or disconnect AC adaptor (for shop display purpose only).
Then reinsert the battery or reconnect AC adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
If you record near radio transmitters or high-voltage lines, the recorded pictures and/or sound may
be adversely affected.
Do not keep objects that may be influenced magnetically close to the speaker.
Magnetised objects such as bank cards, commuter passes, watches, may be adversely affected
by the magnetic influence of the speaker.
Do not extend the supplied cord or cable.
Do not allow camera to come into contact with pesticides or volatile substances (can cause surface
damage or coating to peel).
Never leave the camera and the battery in a car or on a car hood in the summer.
It may cause leakage of the battery electrolyte, a generation of heat, and may cause a fire and the
battery to burst due to the high temperature.
Caring for your camera
To clean your camera, remove the battery, and wipe with a soft, dry cloth.
Use a damp cloth to remove stubborn stains, before wiping with a dry cloth.
Do not use benzene, thinners, alcohol, or kitchen detergent, as these may damage the outer casing
and finish of the camera.
If using a chemically-treated cloth, read the supplied instructions carefully.
When not using for a while
Turn off camera power before removing battery and card (ensure that battery is removed to prevent
damage through over-discharge).
Do not leave in contact with rubber or plastic bags.
Store together with a drying agent (silica gel) if leaving in drawer, etc. Store batteries in cool (15 °C
- 25 °C (59 °F - 77 °F)) places with low humidity (40%RH - 60%RH) and no major temperature
changes.
Charge battery once per year and use completely before storing again.

Table of Contents

Other manuals for Panasonic Lumix DMC-S2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-S2 and is the answer not in the manual?

Panasonic Lumix DMC-S2 Specifications

General IconGeneral
Megapixel14.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels14.5 MP
Image sensor size1/2.33 \
Image formats supportedJPG
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4320 x 3240 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 3232 x 3232, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Optical zoom4 x
Extra/Smart zoom8 x
Focal length range5 - 20 mm
Maximum aperture number6.5
Minimum aperture number3.1
Number of aspheric elements8
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)132 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto
Auto Focus (AF) points23
Auto focusing (AF) modesMulti Point Auto Focus, Single Auto Focus
Closest focusing distance0.05 m
ISO sensitivity100, 200, 400, 800, 1600, 6400
ISO sensitivity (max)1600
ISO sensitivity (min)100
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Flash modesForced off, Forced on, Red-eye reduction, Slow synchronization, Soft
Flash range (tele)1 - 1.6 m
Flash range (wide)0.4 - 3.3 m
Power source typeBattery, USB
Optical viewfinderNo
Scene modesChildren, Night portrait, Panorama, Portrait, Sports, Sunset
Image editingResizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackSingle image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF 2.0, Exif 2.3
Video resolutions320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate30 fps
Video formats supportedM-JPEG
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC
Audio systemMono
Memory slots1
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
USB version2.0
Product colorWhite
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 8.0 Adobe Reader
Battery voltage3.6 V
Battery life (CIPA standard)280 shots
Weight and Dimensions IconWeight and Dimensions
Depth20.6 mm
Width97.9 mm
Height56.6 mm
Weight95 g
Weight (including battery)112 g
