Names and Functions of Main Parts
1 Self-timer indicator (→47)/AF Assist Lamp (→62)
2 Flash (→45)
3 Lens
4 Lens barrel
5 LCD monitor (→88)
6 Power button (→16)
7 Microphone (→25)
8 Shutter button (→20)
9
DMC-FS40 DMC-FS41
Zoom lever (→43)
DMC-FS28 DMC-S5 DMC-S2
Zoom button (→43)
10 [MODE] button (→18)
11 Hand strap eyelet
12 [AV OUT/DIGITAL] socket (→78, 82, 85)
13
[
/ ] (Delete/Return) button (→31)
14 [MENU/SET] button
15 Playback button (→20)
16 Cursor button
17 Tripod receptacle
18 Speaker
19 DC coupler cover
For shop display purpose only
• When using an AC adaptor, ensure that the Panasonic DC coupler (for shop display
purpose only) and AC adaptor (for shop display purpose only) are used.
20 Card/Battery door (→12)
We recommend using
the supplied hand strap
to avoid dropping the
camera.
