- 83 -
Using with your PC
*
1
New folders are created in the following cases:
When pictures are taken to folders containing files numbered 999.
When using cards already containing the same folder number (for example, pictures taken with
other cameras, etc.).
*
2
Note that pictures cannot be uploaded to image-sharing websites if the files in the AD_LUMIX
folder are deleted.
*
3
This folder is not created in the built-in memory.
To cancel connection
Click “Safely Remove Hardware” in the Windows System Tray
When using Windows XP, Windows Vista, Windows 7, or Mac OS X
The camera can be connected to your computer even if you select [PictBridge (PTP)] in
the step on the previous page.
Only picture output can be performed.
It may not be possible to import if there are 1000 or more pictures on the card.
Folder and file names on computer
Do not use any other USB connection cables except the supplied one.
Turn off power before inserting or removing memory cards.
When the battery begins to run out during communication, a warning beep sounds.
Cancel communication via your computer immediately. Use a sufficiently charged
battery.
For more details, consult your computer operating manual.
DCIM (Still/motion pictures)
100_PANA (Up to 999 pictures/folder)
:
101_PANA
:
*
1
999_PANA
MISC (Favourite)
AD_LUMIX (Folder for Web uploading)
*
2,
*
3
LUMIXUP.EXE (Uploading tool)
Windows
Drives are displayed
in “My Computer” or
“Computer” folder.
Mac
Drives are displayed on
the desktop.
(Displayed as “LUMIX”,
“NO_NAME”, or
“Untitled”.)
JPG:
Still pictures
MOV:
Motion pictures

Table of Contents

Other manuals for Panasonic Lumix DMC-S2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-S2 and is the answer not in the manual?

Panasonic Lumix DMC-S2 Specifications

General IconGeneral
Megapixel14.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels14.5 MP
Image sensor size1/2.33 \
Image formats supportedJPG
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4320 x 3240 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 3232 x 3232, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Optical zoom4 x
Extra/Smart zoom8 x
Focal length range5 - 20 mm
Maximum aperture number6.5
Minimum aperture number3.1
Number of aspheric elements8
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)132 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto
Auto Focus (AF) points23
Auto focusing (AF) modesMulti Point Auto Focus, Single Auto Focus
Closest focusing distance0.05 m
ISO sensitivity100, 200, 400, 800, 1600, 6400
ISO sensitivity (max)1600
ISO sensitivity (min)100
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Flash modesForced off, Forced on, Red-eye reduction, Slow synchronization, Soft
Flash range (tele)1 - 1.6 m
Flash range (wide)0.4 - 3.3 m
Power source typeBattery, USB
Optical viewfinderNo
Scene modesChildren, Night portrait, Panorama, Portrait, Sports, Sunset
Image editingResizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackSingle image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF 2.0, Exif 2.3
Video resolutions320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate30 fps
Video formats supportedM-JPEG
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC
Audio systemMono
Memory slots1
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
USB version2.0
Product colorWhite
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 8.0 Adobe Reader
Battery voltage3.6 V
Battery life (CIPA standard)280 shots
Weight and Dimensions IconWeight and Dimensions
Depth20.6 mm
Width97.9 mm
Height56.6 mm
Weight95 g
Weight (including battery)112 g
