Panasonic Lumix DMC-TZ25 User Manual

- 12 -
Charging battery
Charging the battery
We recommend charging in a location where the ambient temperature is between 10 °C
and 30 °C (50 °F to 86 °F) (same for the battery temperature).
Set the camera ON/OFF switch to OFF
■
Charging the battery by connecting the camera to the electrical outlet
Connect the AC adaptor (supplied) and the camera using the USB connection cable
(supplied), and plug the AC adaptor (supplied) into the electrical outlet.
• Be sure to only use the AC adaptor indoors.
■
Charging the battery through the computer
Connect a computer to the camera using the USB connection cable (supplied).
●
It may not be possible to charge the battery from some computers depending on the
computer specifications.
●
If the computer enters hibernation mode during charging, charging may be stopped.
●
If a notebook computer that is not connected to an electrical outlet is connected to
the camera, the battery of the notebook computer will be depleted. Do not leave the
camera and notebook connected for a long period of time.
●
Always connect the USB connection cable to the USB connector on your computer.
Do not connect the USB connection cable to the USB connector of the monitor,
keyboard, printer, or USB hub.
USB connection cable (supplied)
• Always check the direction of the pins and
hold the plug straight to insert or remove it.
(If the cable is inserted in the wrong
direction, the pins could become deformed
and cause faulty operation.)
Align the marks ( to ) and
insert the plug.
Computer
Getting ready:
Turn on the computer.
AC adaptor
(supplied)
Charging lamp

Panasonic Lumix DMC-TZ25 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	12.8 MP
Image sensor size	1/2.3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1600 x 1200, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2448 x 2448, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2992 x 2992, 3264 x 1840, 3264 x 2176, 3264 x 2448, 4000 x 2248, 4000 x 2672, 4000 x 3000
Digital zoom	4 x
Optical zoom	16 x
Extra/Smart zoom	31.3 x
Focal length range	4.3 - 68.8 mm
Maximum aperture number	5.9
Minimum aperture number	3.3
Number of aspheric elements	3
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	384 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.5 m
Flash range (wide)	0.6 - 6.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Memory slots	1
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
HDMI version	-
USB connector	Mini-USB B
HDMI connector type	Mini
Scene modes	Children, Night landscape, Night portrait, Panorama, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Shooting modes	Aperture priority, Movie, Program, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN, RUS
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Product color	Red
Cables included	AC, USB

Weight and Dimensions

Depth	33.4 mm
Width	104.9 mm
Height	57.6 mm
Weight	185 g
Weight (including battery)	208 g
