Panasonic Lumix DMC-ZS15 User Manual

- 139 -
Usage cautions and notes
About AC adaptor (supplied)
●
Keep at least 1 m (3.3 feet) away from AM radio (may cause radio interference).
●
The AC adaptor (supplied) may generate whirring sounds when it is being used. This is not a
malfunction.
●
After use, be sure to disconnect the power supply device from the electrical outlet. (A very small
amount of current is consumed if it is left connected.)
Lens
●
If lens is dirty:
Images may appear slightly white if lens is dirty (fingerprints, etc.). Turn the power on, hold the
extracted lens barrel with your fingers, and gently wipe the lens surface with a soft, dry cloth.
●
Do not leave the lens exposed to direct sunlight.
●
Do not touch the lens barrier, as this may damage lens. Be careful when removing camera from
bag, etc.
When using a tripod or unipod
●
Do not apply excessive force or tighten screws when they are crooked. (This may damage the
camera, screw hole, or label.)
●
Ensure that the tripod is stable. (Refer to the tripod instructions.)
●
You may not be able to remove the card or the battery when using a tripod or unipod.
About 3D viewing
●
Anyone who is hypersensitive to light, suffers from heart disease or is otherwise unwell should avoid
viewing 3D pictures.
• Viewing 3D pictures may have an adverse effect to the individual.
●
If you feel tired, uncomfortable or otherwise strange when viewing 3D pictures, stop viewing at once.
• Continuing to view may cause illness.
• After stopping viewing, please rest appropriately.
●
When viewing 3D pictures, we recommend taking a break every 30 to 60 minutes.
• Viewing for extended periods may cause eye-fatigue.
●
Short-sighted or long-sighted persons, those with differences in the sight of their right and left eyes,
and those with astigmatism are advised to correct their vision by wearing glasses etc.
Stop viewing if you can clearly see a double image while viewing 3D pictures.
• There are differences in the way that different people experience 3D pictures. Please correct your
sight appropriately before viewing 3D pictures.
• You can change the 3D setting of your television or 3D output setting of the unit to 2D.

Panasonic Lumix DMC-ZS15 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	12.8 MP
Image sensor size	1/2.3 \
Image formats supported	JPEG XR
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	[1:1] 2992x2992, 2448x2448, 1920x1920, 1536x1536, 480x480\\r [4:3] 4000x3000, 3264x2448, 2560x1920, 2048X1536, 1600x1200, 640x480\\r [3:2] 4000x2672, 3264x2176, 2560x1712, 2048x1360, 640x424\\r [16:9] 4000x2248, 3264x1840, 2560x1440, 1920x1080, 640x360
Digital zoom	4 x
Optical zoom	16 x
Extra/Smart zoom	19.6 x
Focal length range	4.3 - 68.8 mm
Minimum aperture number	-
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	384 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 1EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.5 m
Flash range (wide)	0.6 - 6.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Audio system	Mono
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
USB version	2.0
HDMI connector type	Mini
Product color	Black
Scene modes	Children, Cuisine, Night, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	ENG, ESP
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	USB
Bluetooth	No

Weight and Dimensions

Depth	33.4 mm
Width	104.9 mm
Height	57.6 mm
Weight	185 g
Weight (including battery)	208 g
