Preparations
Names and Functions of Main Parts
VQT5E94
- 14 -
21 Strap eyelet (→16)
24 [Wi-Fi] antenna
25 GPS antenna (→258)
26 NFC antenna (→194)
27 [Wi-Fi] button (→186)
28 Playback button
Use this to select the Recording Mode or Playback Mode.
29
[Q.MENU/
] / [ ] button
You can display the Quick Menu (→34) and erase pictures (→58).
You can also use this button to return to the previous screen while a menu is displayed (→60).
30 [DISP.] button (→76, 156)
Use this to change display.
31 [Fn] button (→133)
Use this to use registered functions.
32 [MENU/SET] button / Cursor button / Control dial (→16)
●
The illustrations and screens in this manual may differ from the actual product.
21 24 25
28
27
32
29
31
30
26
