Removing Belt
Check and remove hair, string and lint
build-up frequently in the Power Nozzle
brush and brush support areas. If
build-up becomes excessive,
disconnect Power Nozzle from wand
and follow the steps below.
➢ Turn off and unplug vacuum cleaner.
➢ Turn Power Nozzle over.
➢ Unscrew the two (2) Power Nozzle
cover screws.
➢ Turn Power Nozzle right side up.
➢ Press handle release pedal and
lower the swivel.
➢ Lift rear latches up.
➢ To remove cover, grasp the sides
and pull out.
➢ Tilt cover forward from back until
front snaps free.
➢ Lift agitator assembly out.
➢ Remove worn belt.
