Panasonic NA-F135A5WSA

30
Symptoms Points to be checked
Others
Power failure/The breaker
has tripped.
- Operation will resume from the point where it was
stopped when the power is recovered (Auto Restart).
Water outage
- When water supply is recovered, remove the water
supply hose, release turbid water from the faucet,
and then start the washing machine.
The “Stain Master”
program has no effect
(Stains are not removed).
- Pretreatments have been performed? (Hand
washing, applying stain remover, etc.)
- The amount of laundry is under 5.0 kg?
(P. 17)
- The “Stain Master” program is selected according
to the type of stains?
(P. 10)
Powder detergent remains
undissolved.
- Put the detergent in the detergent/bleach inlet.
(P. 12)
There is noise when
water drains out.
- This is normal. It is the noise of the drain pump
working.
Specifications
Model No. NA-F135V5 NA-F135A5WSA NA-F135A5 NA-F115A5WSA NA-F115A5
Rated voltage 220 V 220 V 220-240 V 220 V 220-240 V
Rated frequency 60 Hz 60 Hz 50 Hz 60 Hz 50 Hz
Rated power
consumption
490 W 770 W 510 W 770 W 500 W
Standard water
amount
93 L 86 L
Maximum mass
of dry cloth
13.5 kg 11.5 kg
Product
dimensions
643 mm (W) x 715 mm (D) x
1080 mm (H)
643 mm (W) x 715 mm (D)
x 1060 mm (H)
Product weight 46 kg
Pressure of tap
water
0.01 - 1 MPa
Annual energy
consumption for
SASO 2885
529 kWh 466 kWh - 391 kWh -
Annual water
consumption for
SASO 2885
39820 L 42460 L - 39380 L -
Troubleshooting (continued)
