8. PARTS EXPLODE VIEW AND REPLACEMENT PARTS LIST
Parts List
Screw & Nut
Important safety notice :
Components identified by mark have special characteristics important for safety. When replacing any of these.
8.6 Replacement Parts List : C
NA-W120G1 NA-W100G1 NA-W100B1
NA-W90B1
NA-W80B1
C1 Base A AXW0301-0LS00WA 1 1 1 1 1
C2 Back Panel Small AXW0156-0LS0NKAR 1 1 1 1 1 Small size
C3 Motor Washer A Unit AXW004E-8740NJ 3 3 3 3 3
C4 Motor Wash Unit AXW0401-40104 PS - 1 1 1 1 Saudi
AXW0401-39116 PS - 1 1 1 1 Kuwait, Qatar, Oman, UAE, PGF
AXW0401-41302 PS 1 - - - - Costarica
C5 Motor Washer B AXW0421-0FT00 1 1 1 1 1
C6 Motor Pulley AXW0410-0FM20 1 1 1 1 1
C7 Suspension Unit AXW034J-0FM10 1 1 1 1 1
C8 Motor spin Unit A
XW0401-40406 PS - 1 1 1 1
AXW0401-41402 PS 1 - - - -
C9 Spinner Motor Plate Unit AXW034A-7530A 1 1 1 1 1
C10 Brake Wheel U AXW034E-0FM11 1 1 1 1 1
C11 Flexible Wire Unit AXW015C-0LS00 1 1 1 1 1
C12 Power Cord U AXW004A-77255E PS - 1 1 1 1 Kuwait, Qatar, Oman, UAE
AXW004A-72845E PS - 1 1 1 1 PGF
AXW004A-77405E PS - 1 1 1 1 Saudi
AXW004A-87800 PS 1 - - - - Costarica
C13 Capacitor (wash) AXW0403-7M757 PS - 1 1 1 1 15
µ
F
AXW0403-7W803 PS 1 - - - - 44
µ
F
C14 Capacitor (spin) AXW0403
-7W707 PS - 1 1 1 1 2.5
µ
F
AXW0403-7W907 PS 1 - - - - 12
µ
F
C15 Fuse U AXW014C-32300 PS - 1 1 1 1 250 V, 5 A
AXW014C-32410E PS 1 - - - - 125 V, 12 A
C16 Capacitor Cover AXW0405-5W65N 1 1 1 1 1 Cover wiring connector
C17 Alumunium Tape AXW0439-AL100 1 1 1 1 1 Capacitor (wash)
C18 Alumunium Tape AXW0439-AL200 2 2 2 2 2 Base A
C19 Alumunium Tape AXW0439-0LS00 - 1 1 1 1 Capacitor (spin)
C20 Alumunium Tape AXW2631-0MD00 1 - - - 1 Capacitor cover
1 Special Tapping Screw XTWAXW52
5NJ 3 3 3 3 3 Motor wash - Base A
2 Screw Suspension XTT5+25AJ 3 3 3 3 3 Motor spin - Suspension U
3 Special Bolt XVGAXW818NCJ 1 1 1 1 1 Motor Pulley - Shaft
4 Special Nut XNGAXW803J 1 1 1 1 1 Motor Pulley - Shaft
5 Bind Tapping Screw XTB4+15CJ 2 2 2 2 2 Capacitor - Base A
6 Bind Tapping Screw XTB4+15CJ 10 10 10 10 10 Base A - Tub A
7 Bind Tapping Screw XTB4+12CJ 1 1 1 1 1 Back panel - Base A
REF.
NO.
PART NAME PART NO. SAFETY REMARK
MODEL / QTY
