2.4Whenthe10Afuseisblownduetotheoperation
oftheshortswitch:
TOPPREVIOUSNEXT
WARNING
Whenthe10A250Vfuseisblownduetotheoperationoftheinterlockmonitorswitch,replaceallofthe
components(primarylatchswitch,secondarylatchswitch,shortswitchandpowerrelayB(RY1)).
1.Thisismandatory.Referto“adjustmentsandmeasurements”forthelocationoftheseswitches.
2.Whenreplacingthefuse,confirmthatithastheappropriateratingforthesemodels.
3.Whenreplacingfaultyswitches,besurethemountingtabsarenotbent,brokenordeficientintheirability
toholdtheswitches.
