3.1Adjustmentofprimarylatchswitch,secondary
latchswitchandshortswitch.
TOPPREVIOUSNEXT
1.MountthePrimarylatchswitch,theSecondarylatchswitchandtheShortswitchtothedoorhook
assemblyasshowninILL.
NOTE:
NospecificindividualadjustmentduringinstallationofthePrimarylatchswitch,Secondarylatchswitch
orshortswitchtothedoorhookarerequired.
2.Whenmountingthedoorhookassemblytotheovenassembly,adjustthedoorhookassemblybymoving
itinthedirectionofthearrowsintheillustration,sothattheovendoorwillnothaveanyplayinit.Check
forplayinthedoorbypullingthedoorassembly.Makesurethatthelatchkeysmovesmoothlyafter
adjustmentiscompleted.Completelytightenthescrewsholdingthedoorhookassemblytotheoven
assembly.
3.Reconnecttheshortswitchandcheckthecontinuityofthemonitorcircuitandalllatchswitchesagainby
followingthecomponenttestprocedures.
