5.2PARTSLIST
TOPPREVIOUS
Ref.No.  PartNo. PartName&Description Pcs/Set Remarks
BZ310  AEFBAT2001 BUZZER 1 2.0KHz
C10  EEUFC1C471B ALCHEMCAPACITOR 1 470μF/16V
C11  AECETS1C220B ALCHEMCAPACITOR 1 22μF/16V
C25  ECA2WHG100E ALCHEMCAPACITOR 1 10μF/450V/105°C
C481  AECETS1H010B ALCHEMCAPACITOR 1 1μF/50V
C482  AECETS1HR47B ALCHEMCAPACITOR 1 0.47μF/50V
C483  AECETS1H2R2B ALCHEMCAPACITOR 1 2.2μF/50V
C40C48  AECUU06R102K CHIPCAPACITOR 9 1000PF/50V
C13,C330,C350,C351  AECUU06F103Z CHIPCAPACITOR 4 0.01μF/50V
C12,C14,C220,C440,C484  AECUT06F104Z CHIPCAPACITOR 5 0.1μF/25V
C480  AECUU06F473Z CHIPCAPACITOR 1 0.047μF/50V
C320,C321  AECUU06C220J CHIPCAPACITOR 2 22PF/50V(YTE,TPE,ZPE)
CN1  AEEMMD15509W CONNECTOR 1 9Pin
CN2  AEEMMF00703W CONNECTOR 1 3Pin
CN3  AEEMXH00703B CONNECTOR 1 3Pin
CN4  AEEMMF00D04W CONNECTOR 1 4Pin
CN5  AEEM09FDZBTM CONNECTOR 1 
CN6  AEEMMF00703R CONNECTOR 1 3Pin
CX320  AEYXAT498MA CRYSTALRESONATOR 1 8.00MHz(YTE,TPE,ZPE)
CX320  AEFOS800MG06 CERAMICRESONATOR 1 8.00MHz(EXCEPTYTE,TPE,ZPE)
D28,D220  AESSRCT1A6E DIODE 2 
D40,D41,D222,D223,D224  AESS133T77 DIODE 5 
D25  AERZ511KD10A VARISROR 1 
D26,D27  AERZ102KD10A VARISROR 2 
D180,D181,D182  AESQTLGE260 CHIPLED 3 
DISP1HOLD  A611A4J00XN LCDHOLDER 1 
DISP110  AEDDHJ4X80XN DISPLAY 1 HPE,YPQ,MPQ,TPE,YTE
DISP110  AEDDHJ4X70QP DISPLAY 1 KTE,KPQ,STM,PTE,KUE,ZPE
IC1  MN101C54CDE2 L.S.I. 1 
IC25  AEICP25011HL IC 1 
IC220  AEICU2004GR2 IC 1 
IC480  AEICUPC358G2 IC 1 
IC10  ETXMJ197X1BG SWITCHINGPOWERSUPPLY 1 
Q10  2SD1859TV2Q TRANSISTOR 1 
Q182  AESC43ZKE CHIPDIGITRANSFORMER 1 
Q220  AESAKTA200Y TRANSISTOR 1 
Q221  AESA14EKE CHIPDIGITRANSFORMER 1 
Q440  AESC43XKE CHIPDIGITRANSFORMER 1 
R40R48  AERJ06JJ102R CHIPRESISTOR 9 1K,1/16W,5%
R27,R220,R340,R490,R491  AERJ06JJ103R CHIPRESISTOR 5 10MΩ,1/16W,5%
R223  AERJ06JJ104R CHIPRESISTOR 1 100K,1/16W,5%
R488  AERJ06JJ105R CHIPRESISTOR 1 1MΩ,1/16W,5%
R484  AERJ06JJ154R CHIPRESISTOR 1 150K,1/16W,5%
R211  AERJ06JJ182R CHIPRESISTOR 1 1.8K,1/16W,5%
