10.6.2. NN-T685SF APH/CPH, NN-T675SF APH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ310 AEFBAT2001WQ BUZZER 1 2.0KHz
C343 AECUU06C101J CHIP CAPACITOR 1 100PF/50V
C330,C331 AECUU06R102K CHIP CAPACITOR 2 1000PF/50V
C221,C222,C486,C484 AECUU06F103Z CHIP CAPACITOR 4 0.01µF/50V
C481 AECUU06F473Z CHIP CAPACITOR 1 0.047µF/50V
C12,C340,C440 AECUT06F104Z CHIP CAPACITOR 3 0.1µF/25V
C223,C224 AECUN06F105Z CHIP CAPACITOR 2 1µF/10V
C10 AECETK1V471B AL CHEM CAPACITOR 1 470µF/35V
C13 AECETS1C220B AL CHEM CAPACITOR 1 22µF/16V
C482 AECETS1H010B AL CHEM CAPACITOR 1 1µF/50V
C483 AECETS1HR47B AL CHEM CAPACITOR 1 0.47µF/50V
C485 AECETS1H2R2B AL CHEM CAPACITOR 1 2.2µF/50V
CN1 K1KA03AA0108 CONNECTOR 1 5 Pin
CN2 AEEMMF00703W CONNECTOR 1 3 Pin
CN3 F03524U50AP INV. HARNESS (U) 1
CN4 K1KA04AA0086 CONNECTOR 1
CN5 AEEM9604S15F CONNECTOR 1 15 Pin
CN6 AEEM9604S15C CONNECTOR 1
PIN1,PIN2 AEPINIPS-1E7 PIN 2
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8MHz
IC1 MN101C54CWT L.S.I. 1
IC480 C0ABBZ000017 IC 1
DISP110 AEDDHJ5W00AP LCD 1
DISPL1 F66175W00AP LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D180-D189 AESQPY1112H CHIP-LED 10
D220,D221,D225 B0AACK000004 DIODE 3
D223 B0AACK000004 DIODE 1 (CPH)
D10,D11,D12,D13 AESSRCT1A6-E DIODE 4
D40,D226,D227 B0AACK000004 DIODE 3
D25 AERZ271KD10N VARISTOR 1 270V
D26,D27 AERZ102KD10N VARISTOR 2 1100V (CPH)
Q224 B1GBCFEL0002 CHIP DIGI-TRANSISTOR 1
Q223 B1GBCFEL0002 CHIP DIGI-TRANSISTOR 1 (CPH)
Q226 B1GDCFJJ0002 CHIP DIGI-TRANSISTOR 1
Q182 B1GBCFEL0002 CHIP DIGI-TRANSISTOR 1
Q181,Q220,Q225 B1ABCF000010 CHIP TRANSISTOR 3
Q227 B1ADCF000003 CHIP TRANSISTOR 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
R10,R11,R311 AERDY2TJ102T CARBON FILM RESISTOR 3 1K
Ω
ΩΩ
Ω
,1/4W,5%
R12,R180 AERDY2TJ103T CARBON FILM RESISTOR 2 10K
Ω
ΩΩ
Ω
,1/4W,5%
R290 AERDY2TJ104T CARBON FILM RESISTOR 1 100K
Ω
ΩΩ
Ω
,1/4W,5%
VZ340 AEVNNV6TL103 VARISTOR 1 10K
Ω
ΩΩ
Ω
RY1 AEBGJQC25F18 POWER RELAY 1
RY2 K6B1AZA00011 POWER RELAY 1 (CPH)
ZD10 B0BA5R600016 ZENER DIODE 1
T10 AETP284T0AP LOW VOLTAGE TRANSFORMER 1 120V
SW1-SW4,SW6-SW9,SW11,
SW16,SW17,SW19-SW30
EVQ11L05R SWITCH 23
46
