Panasonic NN-SD967S - Page 76

10.6.3. NN-T665SF APH, T655SF APH, T664SFR APH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 AEFBAT2001WQ BUZZER 1 2.0KHz
C352 AECUU06C101J CHIP CAPACITOR 1 100PF/50V
C330 AECUU06R102K CHIP CAPACITOR 1 1000PF/50V
C222,C486 AECUU06F103Z CHIP CAPACITOR 2 0.01µF/50V
C481 AECUU06F473Z CHIP CAPACITOR 1 0.047µF/50V
C11,C223,C350,C440 AECUT06F104Z CHIP CAPACITOR 4 0.1µF/25V
C220,C221 AECUN06F105Z CHIP CAPACITOR 2 1µF/10V
C12 AECETK1V471B AL CHEM CAPACITOR 1 470µF/35V
C13,C16 AECETS1C220B AL CHEM CAPACITOR 2 22µF/16V
C482 AECETS1H010B AL CHEM CAPACITOR 1 1µF/50V
C483 AECETS1HR47B AL CHEM CAPACITOR 1 0.47µF/50V
C485 AECETS1H2R2B AL CHEM CAPACITOR 1 2.2µF/50V
CN1 K1KA03AA0108 CONNECTOR 1
CN2 AEEMMF00703W CONNECTOR 1 3 Pin
CN3 F03524U50AP INV. HARNESS (U) 1
CN4 K1KA04AA0086 CONNECTOR 1
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8MHz
IC1 MN101C78ADD L.S.I. 1
IC350 C0EBE0000401 IC 1
IC480 C0ABBZ000017 IC 1
DISP110 AEDDHJ7D40AP LCD 1
DISPL1 F66174U20AP LCD HOLDER 1
Q220 B1ADCF000003 CHIP TRANSISTOR 1
Q11,Q181,Q224,Q231 B1ABCF000010 CHIP TRANSISTOR 4
Q182,Q210,Q331 B1GBCFEL0002 CHIP DIGI-TRANSISTOR 3
Q222,Q330 B1GDCFJJ0002 CHIP DIGI-TRANSISTOR 2
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
D180-D183 AESQPY1112CK CHIP-LED 4
D10,D11,D12,D13 AESSRCT1A6-E DIODE 4
D220-D222,D224,D227 B0AACK000004 DIODE 5
D480 AEDNRB721Q DIODE 1
D25 AERZ271KSBN VARISTOR 1 270V
R221 AERDY2TJ102T CARBON FILM RESISTOR 1 1K
Ω
ΩΩ
Ω
,1/4W,5%
R228,R352 AERDY2TJ104T CARBON FILM RESISTOR 2 100K
Ω
ΩΩ
Ω
,1/4W,5%
R225 AERDY2TJ470T CARBON FILM RESISTOR 1 47
Ω
ΩΩ
Ω
,1/4W,5%
ZD10 B0BA5R600016 ZENER DIODE 1
ZD11 B0BA4R400002 ZENER DIODE 1
RY1 AEBGJQC25F18 POWER RELAY 1
T10 AETP284T0AP LOW VOLTAGE TRANSFORMER 1
VZ1 AEVNNV6TL103 VARISTOR 1 10K
Ω
ΩΩ
Ω
47
NN-T695 NN-T685SF
