Location of Controls
q External Air Vent
w Internal Air Vent
e Door Safety Lock System
r Exhaust Air Vent
t Control Panel
y Identification Plate
u Glass Tray
i Roller Ring
o Heat/Vapor Barrier Film
(do not remove)
a Waveguide Cover
(do not remove)
s Door Release Button
d Warning Label
f Menu Label
1$ DHHS Label
1% Power Supply Cord
1^ Power Supply Plug
1& Oven Light
Oven light will turn on during cooking and also
when door is opened.
NOTE:
The illustration is for reference only.
