EVF SECTION
Note:
1. Parts with no Ref. No. in "EXPLODED VIEW" are not supplied.
And some Ref. No. will be skipped. Be sure to make your
orders of replacement parts according to the parts list.
2. The parts indicated by the dotted line are for Ass'y only
and are not supplied.
3. Disregard Ref. No. suffixes when ordering parts. They are used
to describe parts in "Disassembly/Assembly Procedures" section.
13
16
15
17
18
23
22
20
21
14
16
450
450
450
524
524
EVF Case Ass'y
(L-1)
(L-2)
FP951
(not supplied)
44
