Panasonic OLED-201806 - Page 45

LDPP
LED
Drive
LDP5/LDP6
P2
9
TV_SUB_ON
BL_ON
1-4
POWER
Switch
12
POWER_ON
64V(*)
Output
16V
Output
STB5V
Output
(Ex. TNPA6375**
for 65FX6**)
(Ex. TNPA6374** for 65FX6** )
LDP3
5,6
1
19,20
13
LCD Module
A
T-CON
board
LCD Panel
STB3.3V
F16V
PNL12V
A16
44 - 51
12V
3.3V
5V
1.5V
1.1V
3.3V
PNL12V
9
12
14
(*)The DC level is different by the LCD panel.
45
A02
Reference: Voltage Distribution ( A+P+LDP Boards )
only 65FX6**/75FX7** series
(Each models are different pin allocation but operation is same.)
VLED1/2(*)
16V
STB5V
7
1-4
7
P2
1
3
1
3
LDP2
3
Up
convert
<A+P+LDP>
