Aspect ratio 16:9
Projection distance
Diagonal
Projection size Projection distance
Min (Wide) Max (Telephoto)
1.02 m
1.52 m
2.03 m
2.54 m
3.05 m
3.81 m
5.08 m
6.35 m
7.62 m
1.11 m
1.70 m
2.28 m
2.87 m
3.45 m
4.33 m
5.79 m
7.25 m
8.71 m
2.29 m
3.46 m
4.62 m
5.79 m
6.96 m
8.70 m
11.62 m
14.53 m
17.45 m
40˝
60˝
80˝
100˝
120˝
150˝
200˝
250˝
300˝
3´8˝
5´7˝
7´6˝
9´5˝
11´4˝
14´2˝
19´0˝
23´9˝
28´7˝
7´6˝
11´4˝
15´2˝
19´0˝
22´10˝
28´7˝
38´1˝
47´8˝
57´3˝
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
Optional accessories
ET-PKA110H
Ceiling mount
bracket for high
ceilings
ET-LAA110
Replacement
lamp unit
ET-PKA110S
Ceiling mount bracket
for low ceilings
Specifications
Power supply
Power consumption
LCD*
7
panel Panel size
Display method
Drive method
Pixels
Lamp*
8
Lens
Projection size (diagonal)
Brightness*
9
Center-to-corner uniformity
ratio*
9
Contrast ratio*
9
Resolution
Scanning frequency
RGB
YP
BPR (YCBCR)
Video/S-Video
Optical axis shift*
12
Keystone correction range
Terminals
HDMI IN
COMPUTER (RGB) IN
COMPONENT IN
TRIGGER IN/OUT
VIDEO IN
S-VIDEO IN
SERIAL IN
Dimensions (W × H × D)
Weight*
16
Operation noise*
9
Operating temperature
Operating humidly
Supplied accessories
100–240 V AC, 50/60 Hz
350 W (0.08 W in standby mode)
18.7 mm (0.74 in) diagonal (16:9 aspect ratio)
Transparent LCD panel (× 3, R/G/B)
Active matrix
2,073,600 (1,920 × 1,080) × 3, total of 6,220,800 pixels
280 W UHM lamp
Manual zoom (1.33–2.69:1), manual focus lenses,
F 2.0–3.4, f 21.5–43.0 mm
1.02–7.62 m (40–300 inches)
2,800 lm*
10
85%
50,000:1*
11
(full on/full off)
1,920 × 1,080 pixels
f
H: 15 kHz–74 kHz, fV: 24 Hz–85 Hz,
dot clock: 154 MHz or lower
525i (480i), 625i (576i), 525p (480p), 625p (576p),
750 (720)/60p, 750 (720)/50p, 1125 (1080)/60i,
1125 (1080)/50i, 1125 (1080)/24p, 1125 (1080)/60p,
1125 (1080)/50p
f
H: 15.75 kHz, fV: 60 Hz
[NTSC/NTSC4.43/PAL-M/PAL60]
f
H: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Vertical: ±65%, horizontal: ±26%
Vertical: approx. ±30°
HDMI connector × 2, HDMI (Deep Color, x.v.Color*
13
,
CEC*
14
), HDCP compliant, supports HDAVI Control
Version 5
D-sub HD 15-pin (female) × 1 (RGB/YP
BPR/YCBCR × 1)
RCA pin × 3 (YP
BPR/YCBCR)
M3 × 2, 12 V, max. 100 mA (input/output selectable
using on-screen menu)
RCA pin × 1
Mini DIN 4-pin × 1
D-sub 9-pin × 1 for external control
(RS-232C compliant)
470 mm × 151 mm × 380 mm*
15
(18-17/32˝ × 5-15/16˝ × 14-31/32˝ )*
15
Approx. 8.6 kg (19.0 lbs)
29 dB (lamp power: ECO)
0°–40°C (32°–104°F)*
17
20%–80% (no condensation)
Power cord (× 1) (× 2 for PT-AR100EA)
Wireless remote control unit (× 1)
Batteries for remote control (AA/R6 type × 2)
Lens cover (× 1)
Energy-Saving Intelligent Lamp Power Control
Advanced Panasonic digital circuitry intelligently determines the necessary
power output of the lamp depending on the content being displayed by
analyzing more than 3 billion different image patterns. This advanced anal-
ysis process reduces the main power consumption by as much as 10 per-
cent when the Dynamic Iris Pro function is operating, thus saving energy.
Up to 3,000-Hour Lamp Replacement Cycle*
6
and Simple
Maintenance
Panasonic’s proprietary lamp drive system helps maintain lamp perfor-
mance, resulting in a up to 3,000-hour lamp replacement cycle. For easy
maintenance, you can replace the dust filter from the side and the lamp
from the top of the projec-
tor. The filter and lamp are
easily replaced even after
the PT-AR100 is installed
on the ceiling.
Other Features
16-bit (full 12-bit) gamma correction for natural gradation.
Scene-adaptive MPEG noise reduction effectively blocks regular noise
and minimizes mosquito noise.
Scene-adaptive resizing LSI improves quality when resizing 480p images
or those from other sources with resolution lower than the PT-AR100’s
native resolution.
24p compatible.
Progressive cinema scan (3/2 pulldown) and HD IP.
Up to sixteen sets of PICTURE adjustment settings can be stored in
memory with custom names that make them easy to remember.
User equalizing function lets you adjust the high, mid and low gamma
levels.
Screen Area Memory.
User-friendly ergonomic remote control.
Built-in test pattern.
On-screen input guidance.
Auto input search.
Quiet operation: 29 dB (lamp power: Eco).
Normal/Eco lamp power selection.
More Excitement with 2,800 lm of Brightness
Ecology-Conscious Design
Panasonic works from every angle to minimize environmental impact in the
product design, production and delivery processes, and in the performance of
the product during its life cycle. The PT-AR100 reflects the following ecological
considerations.
s No halogenated flame retardants are used in the cabinet.
s Non-coated cabinet for easy recycling.
s Lead-free glass for the lens.
s Standby power consumption of only 0.08 W.
s ECO button on the remote control.
s A sleep-timer that reduces wasteful power consumption.
s RoHS compliant.
*
6 When lamp power is set to Eco. The lamp replacement cycle is up to 2,000 hours when the lamp power is set to Normal. The values above are maximum values when they
are used in cycles of being turned on for 2 hours and off for 0.25 hour. When the lamps are turned on and off more frequently, the lamp replacement cycle is shortened. The
usage environment affects the lamp replacement cycle.
*
7 The projector uses a type of liquid crystal panel that typically consists of millions of pixels. This panel is built with
very high-precision technology to provide the finest possible image. Occasionally, a few pixels may remain turned on (bright) or turned off (dark). Please note that this is an
intrinsic characteristic of the manufacturing technology that affects all products using LCD technology.
*
8 The projector uses a high-voltage mercury lamp that contains high
internal pressure. This lamp may break, emitting a large sound, or fail to illuminate, due to impact or extended use. The length of time that it takes for the lamp to break or
fail to illuminate varies greatly depending on individual lamp characteristics and usage conditions.
*
9 Measurement, measuring conditions, and method of notation all comply
with ISO 21118 international standards.
*
10 In Dynamic mode, with dynamic iris on.
*
11 In Cinema 1 mode, with dynamic iris on.
*
12 Shift range is limited during simultane-
ous horizontal and vertical shifting.
*
13 Effective in Rec. 709 picture mode.
*
14 CEC is an abbreviation for Consumer Electronics Control. Operation may not be possible with
some connected equipment or settings.
*
15 With legs at shortest position.
*
16 Average value. May differ depending on models.
*
17 When [HIGH ALTITUDE MODE] is set to [ON]:
0°C – 35°C (32°F–95°F)
NOTE: A PC is required to read the detailed operating instructions (a PDF file on a CD).
PT-AR100G2 Printed in Japan.
All information included here is valid as of November 2012.
7EIGHTS AND DIMENSIONS SHOWN ARE APPROXIMATE 3PECIFICATIONS AND APPEARANCE ARE
SUBJECT TO CHANGE WITHOUT NOTICE 0RODUCT AVAILABILITY DIFFERS DEPENDING ON REGION AND
COUNTRY 4HIS PRODUCT MAY BE SUBJECT TO EXPORT CONTROL REGULATIONS 4HE PROJECTION DIS-
TANCES AND THROW RATIOS GIVEN IN THIS BROCHURE ARE FOR USE ONLY AS GUIDELINES &OR MORE
DETAILED INFORMATION PLEASE CONSULT THE DEALER FROM WHOM YOU ARE PURCHASING THE
PRODUCT !LL OTHER TRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE TRADEMARK OWNERS
0ROJECTION IMAGES SIMULATED ¥ 0ANASONIC #ORPORATION !LL RIGHTS RESERVED
