Contents
Contents
Read this rst! 2
Chapter 1 Preparation
Precautions for use 17
Cautions when transporting 17
Cautions when installing 17
Security 1 9
DIGITAL LINK 1 9
Cautions on use 1 9
Disposal 20
Accessories 21
Optional accessories 22
About your projector 2 3
Remote control 23
Projector body 24
Using the remote control 2 7
Inserting and removing the batteries 27
Setting the ID number of the remote control 27
Connecting to the projector with a cable 28
Chapter 2 Getting Started
Setting up 30
Installation mode 30
Parts for ceiling mount (optional) 30
Projected image size and throw distance 31
Adjusting adjustable feet 37
Removing/attaching the Projection Lens 38
Removing the Projection Lens 38
Attaching the Projection Lens 38
Connecting 39
Before connecting 3 9
Connecting example: AV equipment 40
Connecting example: Computers 41
Connecting example: Twisted-pair-cable
transmitter 42
Chapter 3 Basic Operations
Switching on/off the projector 44
Connecting the power cord 44
Power indicator 44
Switching on the projector 4 5
When the initial setting screen is displayed 45
Making adjustments and selections 47
Switching off the projector 48
Direct power off function 48
Projecting 49
Selecting the input signal 4 9
Adjusting the focus, zoom, and shift 49
Moving the lens to the home position 5 0
Adjustment range by the lens position shift
(optical axis shift) 5 0
Operating with the remote control 5 1
Switching the input 5 1
Using the SHUTTER/AV MUTE button 5 1
Using the mute function 5 2
Adjusting the volume 5 2
Using the freeze function 5 2
Using the on-screen display function 5 3
Using the presentation timer function 5 3
Using the automatic setup function 5 3
Using the keystone distortion correction
function 5 4
Using the digital zoom function 5 4
Switching the aspect ratio of the image 5 4
Using the P IN P function 55
Using the function button 5 5
Using the status function 5 5
Using the ECO management function 5 5
Chapter 4 Settings
Menu navigation 57
Navigating through the menu 5 7
Main menu 5 8
Sub-menu 5 9
[PICTURE] menu 6 2
[PICTURE MODE] 62
[CONTRAST] 62
[BRIGHTNESS] 63
[COLOR] 63
[TINT] 63
[COLOR TEMPERATURE] 63
[GAMMA] 65
[SHARPNESS] 6 5
[NOISE REDUCTION] 6 5
[IRIS] 6 5
[DAYLIGHT VIEW] 66
[SYSTEM SELECTOR] 66
sRGB-compliant video 67
[POSITION] menu 68
[SHIFT] 68
[ASPECT] 68
[ZOOM] 6 9
[CLOCK PHASE] 70
[KEYSTONE] 70
