Radio Frequency range:
FM; 88.0 - 108.0MHz
AM; 525 - 1710kHz
Intermediate Frequency:
FM; 10.7MHz
AM; 455kHz
Sensitivity:
FM;
3.55 V/50mW output / (-3dB
limit sens.)
AM;
178 V/m/50mW output /
(max.sens.)
Speaker: 10cm (4”)
Output jack: Earphone
Power requirement:
AC; 120V, 60Hz
Battery; DC6V(four R6/LR6, AA, UM-3
batteries)
Power consumption: 3W
Dimensions (W×H×D): 234×122×82mm / (9-1/4”×4-3/4”×
3-1/4”)
Mass (without batteries): 670g (1lb. 7.6oz.)
Note: / Specifications are subject to change without notice. /
Mass and dimensions are approximate.
[Power consumption in standby mode: 0.4W]
2001 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
1. Cabinet Parts Location
