Panasonic RF-2400

Radio frequency range:
FM; 87.50-108.00MHz
AM; 520-1610kHz
Intermediate frequency:
FM; 10.7MHz
AM; 459kHz
Sensitivity:
FM;
3.16 V/50mW output (-3dB
limit sens.)
AM;
141 V/m/50mW output (Max.
sens.)
Output jack: Earphone, 8
Speaker: 10cm
Power output: 770mW (RMS...max.)
Power requirement:
AC; 230-240V, 50Hz
DC; 6V (four R6/LR6, AA, UM-3
batteries)
Power consumption: 3W
Dimensions (W×H×D): 234×122×82mm
Mass (without batteries): 670g
Play time:
(When used at 25°C on a flat, stable surface)
Panasonic alkaline dry cell
battery:
AM; About 47 hours
Fm; About 36 hours
The play time may be less depending on the operating
conditions.
Note:
Specifications are subject to change without notice.
Mass and dimensions are approximate.
Supplied accessory: AC mains lead (RJA0035-
X)...1pc.
2001 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
1. Operation Checks and Component Replacement
Procedures
- This section describes procedures for checking the operation of
the major printed circuit boards and replacing the main
