2. Replacement Parts List
Notes:
- Important safety notice:
Components identified by mark have special characteristics
important for safety. / Furthermore, special parts which have
purposes of fire-retardant (resistors), high-quality sound
(capacitors), low-noise / (resistors), etc. are used. / When
replacing any of components, be sure to use only manufactures
specified parts shown in the parts list.
- The parenthesized indications in the Remarks columns specify the
areas. (Refer to the cover page for area.) / Parts without these
indications can be used for all areas.
- “<IA>, <IB>” marks in Remarks indicates languages of instruction
manuals. / <IA>: English / <IB>: English, Canadian French
Ref. No. Part No. Part Name & Description Pcs Remarks
1 RGWW0004-S KNOB,TUNING 1
2 RKKW0003-H BATTERY COVER 1
3 XEARK160DA-C ROD ANTENNA 1
4 XYN3+F8FY SCREW 1
A1 RJA0065-1D AC CORD 1
A2 RQT5882-P O/I BOOK 1 <IA>(P)
A2 RQT5883-C O/I BOOK 1 <IB>(PC)
K010200000YH
3
